PP Strapping Machine 5–19mm PP Packing Straps for Automatic Strapping Machines

PP Strapping Machine  5–19mm PP Packing Straps for Automatic Strapping Machines

DESCRIPTION OF PP STRAPPING PRODUCTION LINE:

Main features of PP strapping production line

High efficiency----high degree of automation, PLC control system, fast production speed, line speed 200-300 m/min.

High quality----high speed rotation, high output, low power consumption, the finished PP straps produced have good toughness and bending resistance, which meet the requirements of fully automatic strapping machines.

Environmental protection----Use PP new materials or recyclable materials for production, non-toxic, odorless and degradable.

Multi-function----Can produce different specifications of width, thickness, length and weight. Width: 5-19mm, thickness: 0.3-1.2mm.

PP strapping production line process flow:

① Feeding →② stirring →③ pre-drying →④ melting and measuring extrusion →⑤ embryo (belt embryo) cooling and forming →⑥ oven preheating →⑦ primary stretching →⑧ secondary stretching →⑨ embossening → oven tempering and setting → cooling → finished product winding

FeaturesProduct Description

Applications of packing belt production equipment:

Working process of PP strapping equipment:

Raw material preparation----Add PP granules into the extruder hopper.

Extrusion molding----PP granules are melted in the extruder and extruded through the mold.

Cooling and shaping----The extruded strapping tape enters the cooling water tank for cooling and shaping.

Traction and stretching---- The traction machine pulls the strapping belt, and the stretching machine performs stretching treatment.

Embossed treatment---- The embossing machine embosses the surface of the strapping tape.

Shaping oven---- Heat and shape the PP belt again to achieve consistent specifications.

Reeling and packaging----The reeling machine winds the strapping tape into a roll and puts it into storage after packaging.
