Product Details:
|
| Strap Core Type: | Paper/Plastic | Strap Width: | 5-19mm |
|---|---|---|---|
| Strap Tension: | Adjustable | Trademark: | JIATUO MACHINERY |
| Power Consumption: | 80KW | Motor: | 37KW(Gugao) |
| Power Supply: | 380V/220V(customizable) | Applicable Raw Materials: | PP Polypropylene New Material/recycled Material |
| Thickness: | 0.3-1.2mm | Capacity: | 100-120kg/H |
| Highlight: | PP strap making machine with PLC control,industrial plastic strapping machine adjustable tension,high efficiency PP packing strap machine |
||
| Model | PP-2 | PP-3 | PP-4 | PP-6 |
|---|---|---|---|---|
| Production material | PP new raw materials | PP new raw materials | PP new raw materials | PP new raw materials |
| Number of strips produced | 2 | 3 | 4 | 6 |
| Output bandwidth (mm) | 5-19mm | 5-19mm | 5-19mm | 5-19mm |
| Tape thickness (mm) | 0.4-1.2 | 0.4-1.2 | 0.4-1.2 | 0.4-1.2 |
| Extrusion capacity (kg/h) | 100-125kg/H | 180-220kg/H | 250-290kg/H | 350-375kg/H |
| Maximum linear speed (m/min) | ≥260 | ≥260 | ≥260 | ≥260 |
| PLC control system | PLC | PLC | PLC | PLC |
| Screw model | 90 | 100 | 110 | 125 |
| Module | Technical Configuration | Stability/Performance Benefit |
|---|---|---|
| Traction System | 5-roller traction structure | Provides stable traction, reduces fluctuations |
| Cooling System | Circulating cooling + multi-guide forming | Controls shrinkage rate, ensures dimensional consistency |
| Screen Changer System | Automatic non-stop screen changer | Avoids shutdowns, improves continuous production capacity |
| Winding System | Constant tension winding | Ensures neat and consistent winding |
| Control System | PLC (supports storage of 99 recipes) | Reduces repeated adjustments, improves consistency |
