Single Screw Plastic PP Strap Making Machine With 4nets Automatic Changer And PLC Control

Single Screw Plastic PP Strap Making Machine With 4nets Automatic Changer And PLC Control
Single Screw Plastic PP Strap Making Machine With 4nets Automatic Changer And PLC Control Single Screw Plastic PP Strap Making Machine With 4nets Automatic Changer And PLC Control Single Screw Plastic PP Strap Making Machine With 4nets Automatic Changer And PLC Control Single Screw Plastic PP Strap Making Machine With 4nets Automatic Changer And PLC Control Single Screw Plastic PP Strap Making Machine With 4nets Automatic Changer And PLC Control

Large Image :  Single Screw Plastic PP Strap Making Machine With 4nets Automatic Changer And PLC Control

Product Details:
Place of Origin: CHINA
Brand Name: JIATUO CHINA
Certification: IS CEO
Model Number: JTPP-100
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: plastic film
Delivery Time: 30-40days
Payment Terms: L/C, T/T

Single Screw Plastic PP Strap Making Machine With 4nets Automatic Changer And PLC Control

Description
Strap Thickness: 0.4-1.2mm Strap Width: 5-19mm
Warranty: 1 Year Key Selling Points: Leading German And Japanese Advanced Technology
Power Consumption: 80KW Strap Color: Red/ Green/ Black/ Yellow/ White
Screw Diameter (mm): 100mm Applicable Raw Materials: Recycled Material And Polypropylene
Highlight:

single screw PP strap making machine

,

PLC control PP strap machine

,

automatic changer strap making machine

Single Screw Plastic PP Strap Making Machine With 4nets Automatic Changer And PLC Control


                                                      PP Strap Making Machine Production Line

Characteristic:

The PP strap extrusion line making machine is developed by our company and combines European advanced technology. It has the advantages of unique structure, advanced configuration, fully automatic, easy operation, high output, good plasticization, stability and reliability.
PP strap produced by our machine has the moderate rigidity strength, good flexibility, creep resistant, environmental stress crack resistance and favorable hot melting property.



                                            Technical Parameters of PP strap extrusion line



TypeJTPP-90JTPP-100JTPP-110JTPP-125JTPP-135JTPP-90/65JTPP110/75
Strap of number23468

2

Sandwich belt

4

Sandwich belt

width5-19mm5-19mm5-19mm9-19mm9-19mm9-19mm9-19mm
Thickness0.4-1.2mm
Reducer mode200200225250280200/173225/173
Screen changerAutomatic/ Manual
Production capacity80-120kg/H180-200kg/H220-250kg/H350-370kg/H460-500kg/H80-120kg/H180-200kg/H
Screw typeSingle screwDouble screw

Single Screw Plastic PP Strap Making Machine With 4nets Automatic Changer And PLC Control 0

Function of PP strap making machine
1) PP raw materials do not need to separate the dry and water treatment . There are automatic circulation on preheating and drying that save a large number of equipment investment and reduce the production cost by 30%;
2) Utilizing the retrieving bottle slice as raw materials that reducing the cost to a great extent;
3) Low Energy consumption, but high production capability;
4)Easy to operate, save the manpower and two persons for one production line on average

Application of PP strapping
 Single Screw Plastic PP Strap Making Machine With 4nets Automatic Changer And PLC Control 1Single Screw Plastic PP Strap Making Machine With 4nets Automatic Changer And PLC Control 2

Our Services



1.Before order: We will provide relevant information on various technology and business consulted by customers. If clients want to visit our company, we will offer all they need for convenience.
2.During order: company designs groundsill installation chart for water, electricity and gas of equipment basing on real condition and customers' requirements and provides detail order list and matching manufacturer for reference for customer.
3.After equipment arrival, our service personnel will arrive at posted locale for installation, debugging, training and technology transfer till customers can operate independently and manufactures eligible product. Service personnel have to arrive at customer's locale in time when we provide service for client again.
4. After order: we will offer 12months after sales service freely, but our service will be life-long. if some parts are broken, we will send them by express, air or ship as soon as we can.

FAQ

For PP(polypropylene) strapping band extrusion line

  • What about the output of PP strapping band extrusion line? 150kg/hr, 250kg/hr, 350kg/hr, 500kg/hr.
  • What about the size of strap that the PP strap machine can make? Width: 5-32mm; Thickness: 0.4-1.2mm;
  • What about the installation power of the PP strap machine? 90kw/120kw/150kw/250kw;
  • What about the maximum tensile strength of the strap? it depend on the material you use
  • What about the running speed of machine? 200-300m/min;
  • What about the usage of PP strap? Packing boxes, money, paper;
  • Will the strap be used for automatic strapping tool or manual tool? Both.

Single Screw Plastic PP Strap Making Machine With 4nets Automatic Changer And PLC Control 3
