Automatic Grade PET Strap Making Machine With Large 4.5m2 Filter And 5000L Dehumidifie Barrel

Automatic Grade PET Strap Making Machine With Large 4.5m2 Filter And 5000L Dehumidifie Barrel
Automatic Grade PET Strap Making Machine With Large 4.5m2 Filter And 5000L Dehumidifie Barrel Automatic Grade PET Strap Making Machine With Large 4.5m2 Filter And 5000L Dehumidifie Barrel Automatic Grade PET Strap Making Machine With Large 4.5m2 Filter And 5000L Dehumidifie Barrel Automatic Grade PET Strap Making Machine With Large 4.5m2 Filter And 5000L Dehumidifie Barrel Automatic Grade PET Strap Making Machine With Large 4.5m2 Filter And 5000L Dehumidifie Barrel

Large Image :  Automatic Grade PET Strap Making Machine With Large 4.5m2 Filter And 5000L Dehumidifie Barrel

Product Details:
Place of Origin: Shenzhen, China
Brand Name: JIATUO
Certification: CE, ISO
Model Number: JTPET-90
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plastic film or other standard package for sea shipping
Delivery Time: 50~55 working days
Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability: 50 set/month

Automatic Grade PET Strap Making Machine With Large 4.5m2 Filter And 5000L Dehumidifie Barrel

Description
Product Type: PET Strap Making Machine Raw Material: PET Flakes Or 100% Recycled Material
PET Strap Width: 9-32mm PET Thickness Range: 0.6-12mm
Capacity: 200~350kg/h Motor: Siemens
Driven Type: Electric Product Color: Green/Pink/yellow/black
Voltage: According To Customer's Factory Application: Packaged Material
After-sales Service Provided: Video Technical Support, Online Support Warranty: 1 Year

https://www.strap-makingmachine.com/sale-36857726-plastic-steel-strap-making-machine-3-lines-300-360kgs-h-pre-drying-tower-4000l-with-iso.html

Automatic Grade PET Strap Making Machine With Large 4.5m2 Filter And 5000L Dehumidifie Barrel


PRODUCT DESCRIPTION OF PET STRAP MAKING MACHINE

This machine is mainly used to make PET strap

Our machines adopts the PLC control to realsize the whole line auotmatic production.

Using the melting pump and pressure sensor ensure the production stable and strap quality control.

The raw material can be 100% recycled pet flakes from the waste pet bottles,or virgin material or mixed with each other.


PARAMETER OF PET 3STRAPS OUTPUT PRODUCTION LINE



Name PET plastic steel belt production line (4straps output)
Applicable raw materials Bottle flake material, 100% broken material
Number of screws Single Screw
Screw size Ø110
Number of extruded belts 3
Width range 9-32mm
Thickness range 0.6-1.2mm
Production capacity 300-350kg/h (according to the weight of each meter)
screen changer Double cylinder / single cylinder

Automatic Grade PET Strap Making Machine With Large 4.5m2 Filter And 5000L Dehumidifie Barrel 0



Processing Flow of PET strap extrusion line

Auto loader→Crystallizing and drying system →Extruder→Mould→ Cooling Tank→Preheating unitOven→ Stretching unitEmbossing machine Tensioning heat calibrator unitHaul-off machine →Winder


Advantages of PET strap

  • Use 100% Recycled PET/PP Flakes to reduce the cost.
  • Good dehumidifer drying system(Crystallization system optional ) to ensure the material equal dryer to produce high quality strapping.
  • Special design hot forming tensile tank to make good forming ,equal width,straight strap.

Application of PET belt making machine

PET packaging tape, also known as plastic steel tape, is a new type of binding tape that replaces steel tape. It is widely used in industries such as cotton spinning, chemical fiber, metallurgy, casting, can making, refractory materials, ceramics, brick making, glass, paper making, furniture, tobacco, wood, electronics, etc.



Automatic Grade PET Strap Making Machine With Large 4.5m2 Filter And 5000L Dehumidifie Barrel 1



FAQ



1. Q: How can I purchase your goods?
A: Please choose your perfect item and tell us your size, quantity and packing you want.
2. Q: How long is the lead time?
A: Normal order within 10-30 days after deposit.
3. Q: Do you offer sample?
A: Samples can be sent for your reference, but charge is required, after making formal order, the cost of samples will be cut from the total amount.
4.Q: What is the MOQ on your products?
A: Small quantity can be acceptable, depends on the stock.



Automatic Grade PET Strap Making Machine With Large 4.5m2 Filter And 5000L Dehumidifie Barrel 2
