5-19mm Width PP Strap Production Line By Thickness Error Within 0.03mm Longer Length

Large Image : 5-19mm Width PP Strap Production Line By Thickness Error Within 0.03mm Longer Length

Product Details:

Place of Origin:	CHINA
Brand Name:	JIATUO CHINA
Certification:	IS CEO
Model Number:	JTPP-90

Payment & Shipping Terms:

Minimum Order Quantity:	1 SET
Price:	Negotiable
Packaging Details:	plastic film
Delivery Time:	30-40days

Contact Now

5-19mm Width PP Strap Production Line By Thickness Error Within 0.03mm Longer Length

Description

Video Outgoing-inspection:	Provided	Trademark:	JiaTuo China
Name:	PP Strap Making Machine	Strap Core Type:	Paper/Plastic
Strap Speed:	>260m/min	Strap Color:	Red/ Green/ Black/ Yellow/ White
Motor:	Siemens	Winder:	Double Station Winder
Thickness:	0.4-1.2mm	Width:	5-19mm
Screw:	Single/double	Capacity:	120-150kg/H
Highlight:	0.03mm PP Strap Production Line , 19mm Width PP Strap Production Line , 5mm Width PP Strap Production Line

5-19mm Width PP Strap Production Line By Thickness Error Within 0.03mm Longer Length

Technical Parameters of 2 straps output banding machine

Product Name	PP Strap Band Extrusion Line
Material	PP Polypropylene New Material/recycled Material
Strap Strength	350-650kg
Production Capacity	250-300kg/h
Winding Method	Manual/automatic
Video Outgoing-Inspection	YES
Equipment Layout Diagram	Customized
Equipment Voltage	Three-phase 380v /50Hz ( Customized )
Warranty	1 Year
Screw Material	38CrMoALA

Product Description of PP tape making machine

The PP Strap Making Machine is an advanced, fully automated system designed for producing high-quality PP straps. Equipped with a video inspection system, it ensures consistent strap quality. Ideal for packaging, strapping, binding, and reinforcing, this machine is reliable, efficient, and maximizes productivity. It offers a cost-effective solution, making it the perfect choice for any strap production business
5-19mm Width PP Strap Production Line By Thickness Error Within 0.03mm Longer Length 0
The extrusion Line consist of the following parts

Material→Stirring raw material→Pre crystallization drying→Extruding→Cooling→Oven preheating→Primary stretching→Secondary stretching→Embossing→Hot forming→Cooling→Winding(finished product)

Feature of PP strap making machine

1.Equipped with a non-stop automatic screen changer, the screen change does not need to be stopped,and the benefit is maxmize. 4 net circulation large area filtering, no need to change the net frequently.
2.The unique cooling cycle system and multiple sets of shaped guide rails make the packing belt cooler and shrink better and more accurate in size. The internal reciprocating winding method makes full use of heat energy and effciently reduces power loss.
3.The equipment adopts intelligent PLC Chinese/English control system, simple to understand, beautiful, durable, long life, low failure rate. The equipment has an exclusive parameter memory system, the data of each specification after production can be stored,the next production can directly call out the parameters.
4.The equipment is equipped with a defecation-correcting device, and the winding is neat and in the shape of knife cutting. The finished products are packed with good color and quality.
