PP strapping band making machine 5-15mm automatic PP strap production line PLC control system
Description of pp strapping band making machine:
PP strapping band making machine is a high-end equipment used to produce PP strapping for a wide range of uses.
Raw materials------100% polypropylene new material or recycled material
Control method------ PLC control system, which can be set to different languages.
Motor------The equipment is driven by Siemens motor, which has stable and reliable performance and low failure rate.
Line speed------ 200-300 m/min
A key component of PP strapping band making machine----------- WRAPPING MACHINE
You can use either a semi-automatic wrapping machine or a fully automatic wrapping machine.
----WRAPPING MACHINE
Semi-automatic wrapping machine (Low failure rate, long service life, changing specifications requires changing gears and grooves)
----WRAPPING MACHINE
Automatic wrapping machine (Fast winding speed, PLC control system, changing specifications does not require changing gears or belt slots, one-button operation)
PP strapping band making machine
PP strapping band making machine
pp packing strap making machine
pp strapping roll manufacturing machine
pp strapping roll making machine
pp packing belt machine
EXTRUSION PARAMETERS TABLE
| Model |
PP-2 |
PP-4 |
PP-6 |
PP-8 |
PP-10 |
PP-12 |
| Raw material |
100% PP polypropylene new material/recycled material |
| Number of tapes |
2 |
4 |
6 |
8 |
10 |
12 |
| Width(mm) |
5-19 |
5-19 |
5-19 |
5-19 |
5-19 |
5-19 |
| Thickness(mm) |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
| Line speed(m/min) |
≧260-300 |
| PLC control system |
PLC |
PLC |
PLC |
PLC |
PLC |
PLC |
| Screw Model |
90 |
110 |
125 |
135 |
135 |
135 |
| Reducer model |
200 |
220 |
250 |
280 |
280 |
280 |
| Winding machine |
Automatic winding machine /Semi-automatic winding machine |
| Screen Changer |
Automatic/Manua |
| Production capacity 24H |
2.5-3T |
6-7T |
8-9T |
10-11T |
12-13T |
13--14T |
FINISHED PP STRAPPING BELT:
Features:
Good plasticity
Strong breaking force
Bending resistance
Low density
Widely used in many fields, including but not limited to ogistics, packaging, transportation, electronic products, hardware, home appliances, clothing, etc.
ABOUT AFTER-SALES
We provide comprehensive technical support and service for our PP strapping band making machine. Our team of experienced technicians can provide a variety of services, including:
Pre-sales:
1.Layout plan of PP strapping band making machine.
2.Analysis of the cost of PP strapping band making machine
3.Raw materials that can be used for PP strapping band making machine
After-sales service:
1.Water and electricity circuits of PP strapping band making machine, circuit drawings, etc.
2.Installation, commissioning and training of PP strapping band making machine.
3.Maintenance service of PP strapping band making machine.
4.Regular maintenance and repair
5.Troubleshooting and diagnosis
6.Software updates and upgrades
7.Spare parts and accessories
8.Training and technical advice
FAQ
Q:What is the voltage of PP strapping band making machine?
A:380V/50HZ, we support customization
Q:What is the length of the PP strapping belt?
A: L:36 M.
Q:Where is the PP strapping band making machine produced?
A:We are from China.
Q:Can PP strapping band making machine provide after-sales service?
A:Yes, we have professional after-sales engineers who provide 24-hour online guidance.
Q:Is the quality of PP strapping band making machine stable?
A:We have 30 years of manufacturing experience, and have their own PP strapping band making machine plant, equipment quality is stable, the process is worth choosing.
Q:Does PP strapping band making machine support customization?
A:We are a manufacturing plant that can customize model size, extrusion capacity, voltage and so on according to customer requirements.
Q:What does the wrapping machine part of the PP strapping band making machine look like?
A:Equipped with Automatic wrapping machine/semi-automatic wrapping machine.
