Product Details:
Place of Origin: CHINA
Brand Name: JIATUO MACHINERY
Certification: IS CEO
Model Number: JTPP-90
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: plastic film
Delivery Time: 30-40days

100% Recycled Material Use PP Belt Production Line With Small Tolerance Of Width Thickness Longer Length And Tension Strength

Description
Screw Diameter (mm): 110*3300mm Extruder: Single Or Double Screw
Applicable Raw Materials: Recycled Material And Polypropylene Strap Speed: >280m/min
Strap Thickness: 0.4-1.2mm Automatic Grade: Fully Automatic
Winder: Double Station Winder Strap Tension: Adjustable

100% Recycled Material Use PP Belt Production Line With Small Tolerance Of Width Thickness Longer Length And Tension Strength​



Technical Parameters of PP strap production line



Item Description
Product Name PP Strap Making Machine
Strap Material PP Recycle Material/New Raw Material
Strap Core Type Paper/Plastic
Strap size 5-19mm width  0.4-1.2mm thickness
Motor GUOMAO
Strap Tension Adjustable
Extruder 2straps output
Strap Color By Customer's Requirement
Warranty 1 Year
Strap Thickness 0.4-1.2mm
Trademark JiaTuo China
Key Focus PP Strap Manufacturing Machine, Plastic Strap Manufacture Equipment, Polypropylene Strap Manufacture Equipment



General descriptions:



PP strap production line is used to produce mechanical or manual bands with 100% PP recycled granules as materials, if raw materials, it will be better. This kind of band is widely used in the packing of kinds of fields such as mines, general merchandise, weaving, electrical equipment, apparatus, architecture, medicine, etc.

100% Recycled Material Use PP Belt Production Line With Small Tolerance Of Width Thickness Longer Length And Tension Strength 0

Features of PP strip production line



1. Flexible Extrusion Technology – Equipped with both twin-screw and single-screw extrusion systems, allowing customization based on production needs.

2. Cost-Efficient Material – Uses 100% recycled material, reducing raw material costs while supporting sustainability.

3. Fully Automated PLC Control – Ensures precise and efficient production with minimal manual intervention.

4. Stable and Uniform Extrusion - Pressure sensors and precision die head design ensure stable plasticization and consistent output.

5. Advanced Drying System – High-performance dehumidifier ensures optimal material dryness, resulting in strapping with high tensile strength and superior impact resistance.



Application of PP strapping



Packaging and Logistics:
PP strapping is widely used to secure cartons, boxes, and packages, ensuring safe and stable transportation of goods.

Printing and Paper Industry:
It is ideal for bundling paper rolls, newspapers, and magazines, facilitating efficient storage and shipment.

Food and Beverage Industry:
PP strapping effectively secures bottled beverages, canned goods, and other packaged food items, maintaining product integrity during transit.

Agriculture:
It is commonly used for bundling crops, hay bales, and other agricultural products, providing durability and ease of handling.

100% Recycled Material Use PP Belt Production Line With Small Tolerance Of Width Thickness Longer Length And Tension Strength 1
After sales service

1. we given client the details technician offer, sign the sales contract etc
2. we supply the details layout, installation instruction, technician support for the clients
3. we arrange engineer to install the machinery and training the workers for client
4. We have 24hours team to solve the after sales problem
5. We have free spare parts with the machine
6. We supply long term spare parts for every customer
7. We always up date the new technology to every customer
100% Recycled Material Use PP Belt Production Line With Small Tolerance Of Width Thickness Longer Length And Tension Strength 2
