Customized plastic machinery PP tape making machine PP packaging tape production equipment for high-end PP extrusion equipment
PRODUCT DESCRIPTION:
1. Screw:The screw of the PP strapping tape production line is made of 38CrMoALA material, a special screw for extruders, with good plasticization and uniform extrusion, ensuring the durability and long-term performance of the equipment.
2.Raw materials: The raw materials of the PP strapping tape production line can be made of PP polypropylene new materials or recycled materials, with low manufacturing costs.
3.Screen changer: The screen changer of the PP strapping tape production line adopts an automatic screen changing device, a 4-net circulation system, a large filtration area, and no need to stop the machine to replace the filter screen.
4.PLC control system: The PP strapping belt production line adopts PLC control system, touch screen operation, and easy debugging.
The PP strapping tape production equipment adopts a PLC microcomputer control system, which is simple to operate, stable in operation, and can automatically memorize the production parameters of strapping tapes of different specifications,It is easy to operate, runs stably, and can automatically memorize the production parameters of strapping tapes of different specifications.
5.Winding: The PP strapping tape production line can be equipped with an automatic winding machine or a semi-automatic winding machine. (The automatic winding machine can automatically wind, change rolls, and stop automatically, without manual operation, reducing labor costs)
Features:
The PP strapping tape production line can produce PP strapping tapes of different colors according to customer requirements, including: red, green, blue, black, yellow, transparent, white, etc.
The PP strapping tape production line can use twin-screw extrusion or single-screw extrusion according to customer requirements, and can produce all-plastic PP tapes or sandwich PP tapes.
Technical Parameters:
| Model |
PP-2 |
PP-4 |
PP-6 |
PP-8 |
PP-10 |
PP-12 |
| Raw material |
PP polypropylene new material/recycled material |
| Number of tapes |
2 |
4 |
6 |
8 |
10 |
12 |
| Width(mm) |
5-19 |
5-19 |
5-19 |
5-19 |
5-19 |
5-19 |
| Thickness(mm) |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
| Line speed(m/min) |
≧260-300 |
| PLC control system |
PLC |
PLC |
PLC |
PLC |
PLC |
PLC |
| Screw Model |
90 |
110 |
125 |
135 |
135 |
135 |
| Reducer model |
200 |
220 |
250 |
280 |
280 |
280 |
| Winding machine |
Automatic winding machine /Semi-automatic winding machine |
| Screen Changer |
Automatic/Manua |
| Production capacity 24H |
2.5-3T |
6-7T |
8-9T |
10-11T |
12-13T |
13--14T |
The main components of PP strapping equipment:
Feeder---- transfer PP raw materials into the machine.
Extruder----heat and melt the PP raw materials and extrude them into shape.
Molding mold---- make the molten PP tape embryo pass through the mold to form a strip.
Cooling water tank----cool the extruded PP tape embryo to ensure its shaping.
Tractor----pull out the cooled strapping tape to maintain a stable production speed.
Oven---- heat the strapping tape to improve its strength and toughness.
Embossing machine---- emboss the surface of the strapping tape to increase friction and prevent slipping.
Shaping oven----heat again, shape, and make the PP tape more standardized.
Reeler---- reel the strapping tape into rolls for easy storage and transportation.
Applications:
Installation and commissioning service:
When the contract PP equipment is installed, the seller's technical personnel will arrive at the buyer's installation site to provide guidance services.
The seller's relevant engineering and technical personnel are responsible for the installation and commissioning of the contract production equipment, trial production process, qualified inspection of finished products, and on-the-job training of production line workers.
The seller's relevant engineering and technical personnel are responsible for the analysis and proportion of various raw material formulas of the contract production equipment,
FQA:
Q:What is the voltage of PP strapping equipment?
A:380V/50HZ, we support customization
Q:Can the PP strapping production equipment be customized according to the factory length?
A:Yes, we can customize the length according to the customer's factory size.
Q:Where is the PP strapping equipment produced?
A:We are from China.
Q:Can PP strapping equipment provide after-sales service?
A:Yes, we have professional after-sales engineers who provide 24-hour online guidance.
Q:Is the quality of PP strapping equipment stable?
A:We have 30 years of manufacturing experience, and have their own PP packaging belt production plant, equipment quality is stable, the process is worth choosing.
Q:Does PP strapping equipment support customization?
A:We are a manufacturing plant that can customize model size, extrusion capacity, voltage and so on according to customer requirements.
