100-120Kg/H PP Strap Band Production Line With Double Embossing To Make 5-19mm Width
PP strap band extrusion line is mainly for producing PP strap.
The raw material can be 100% recycled material,which can reduce the produce cost and get a good profit. And the Pp bale is the substitution of the steel strap and has a lot of advantages such good extension,high temperature resistant,easy use.
Process flow of PP packing belt production line
① Feeding →② mixture material→③ pre-drying →④ melting and measuring extrusion →⑤ belt embryo cooling and forming →⑥ oven pre-heating →⑦ primary stretching →⑧ secondary stretching →⑨ embossing → oven tempering and setting → cooling → finished product winding
Tips: if you have a choose of printing that you can printing first and then embossing in the project of eight.
Specification of PP straps double output making machine
| Item |
Product name |
Detailed parameters |
| 1 |
Materials |
PP polypropylene new material/recycled material |
| 2 |
Product |
PP strap |
| 3 |
Capacity |
100-150kg/h |
| 4 |
Total install power |
60kw, (Operating power 50-55%) |
| 5 |
Strap width |
5mm-19 mm |
| 6 |
Thickness |
0.4 mm-1.2 mm |
| 7 |
Manpower |
1-2person/shift |
| 8 |
Workshop required |
L (30m) ×W (2m) ×H (4m) |
| 9 |
Power source |
380V, 50Hz, 3Phase |
| 10 |
Electric components |
Schneider |
| 11 |
Inverter |
INVT |
| 12 |
Switches+Thermostat |
Taiwan Fotek |
| 13 |
Motor power |
Gugao |
| 14 |
Solid state relay |
Taiwan Fotek |
| 15 |
Bearing |
FSB |
Advantage of PP belt making machine
1-Use 100% recycled material to reduce the cost
2-Good drying system to ensure the material equal dry to produce high quality strapping
3-Special design hot forming tensile tank to make good forming, equal width, straight strap.
FAQ
Q: What will you do for the order?
A: Our service likes below:
---------Before order: We will provide relevant information on various technology and business consulted by customers. If clients want to visit our company, we will offer all they need for convenience.
------During order: company designs groundsill installation chart for water, electricity and gas of equipment basing on real condition and customers' requirements and provides detail order list and matching manufacturer for reference for customer.
After equipment arrival, our service personnel will arrive at posted locale for installation, debugging, training and technology transfer till customers can operate independently and manufactures eligible product. Service personnel have to arrive at customer's locale in time when we provide service for client again.
------ After order: we will offer 12months after sales service freely, but our service will be life-long. if some parts are broken, we will send them by express, air or ship as soon as we can
