Customized high quality 5-19mm PP strapping tape production line PP packaging tape equipment for 24-hour non-stop screen replacement
Product Description of PP strapping tape production line:
Technical parameters of 4 straps making machine:
1.PP packaging equipment can produce plastic raw materials: recycled material or PP polypropylene new material production packaging belt;
2.PP packing belt equipment adopts high precision and high quality screw, adopts well-known brand, unique parameter design, has the advantages of large extrusion capacity, good plasticization, high hardness and wear resistance; Equipped with quantitative extrusion system, the width and thickness of the belts produced are the same, the error range is small, in line with the national acceptance standards for packaging belts;
3.PP packing belt production equipment is equipped with a moving net changer, 24 hours non-stop net change, 4 net circulation board, large filtering area.
EXTRUSION PARAMETERS TABLE
| Model |
PP-2 |
PP-4 |
PP-6 |
PP-8 |
PP-10 |
PP-12 |
| Raw material |
PP polypropylene new material/recycled material |
| Number of tapes |
2 |
4 |
6 |
8 |
10 |
12 |
| Width(mm) |
5-19 |
5-19 |
5-19 |
5-19 |
5-19 |
5-19 |
| Thickness(mm) |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
| Line speed(m/min) |
≧260-300 |
| PLC control system |
PLC |
PLC |
PLC |
PLC |
PLC |
PLC |
| Screw Model |
90 |
110 |
125 |
135 |
135 |
135 |
| Reducer model |
200 |
220 |
250 |
280 |
280 |
280 |
| Winding machine |
Automatic winding machine /Semi-automatic winding machine |
| Screen Changer |
Automatic/Manua |
| Production capacity 24H |
2.5-3T |
6-7T |
8-9T |
10-11T |
12-13T |
13--14T |
PP strapping equipment---Features:
Raw materials-----PP strapping equipment can produce plastic raw materials: 100% recycled materials or PP polypropylene new materials to produce strapping tape;
Screw-----The equipment adopts high-precision high-quality screws, using well-known brands, unique parameter design, with the advantages of large extrusion volume, good plasticization, high hardness and wear resistance; equipped with a quantitative extrusion system, the width and thickness of the produced belts are the same, the error range is small, and it meets the national strapping tape acceptance standards;
Automatic screen changer---Equipped with a non-stop automatic screen changer, the screen change does not require shutdown, maximizes efficiency, 4-net circulation large-area filtration, no frequent screen change is required.
Applications of PP strapping tape production line:
The PP strapping tape production line is a high-end intelligent equipment with a PLC control system, a special screw for the extruder, a non-stop screen changer, etc. The PP strapping tapes produced are of consistent specifications and beautiful appearance, and are widely used in many industries.
PP strapping equipment adopts advanced technology to ensure high efficiency and precision of production. The machine is easy to operate, and the PLC touch screen control system is ideal for various specifications, supports multiple languages, and is easy to debug.
Services :
Our PP strapping equipment provides comprehensive technical support and services. We have an experienced technical team that can quickly provide a variety of services, including:
Pre-sales:
1. Layout of PP strapping equipment.
2. Analysis of finished product manufacturing costs of PP strapping equipment.
3. Analysis of raw materials used in PP strapping equipment.
After-sales service:
1. Waterway diagram, circuit diagram, pipeline connection drawings, etc. of PP strapping equipment.
2. Installation, commissioning and training of PP strapping equipment.
3. Repair service of PP strapping equipment.
4. Regular maintenance and repair
5. Fault diagnosis
6. Software update and upgrade
7. Spare parts and accessories
8. Training and technical consultation
