Double Screw 5mm PP Strap Production Line With Long Length And Flexible

Double Screw 5mm PP Strap Production Line With Long Length And Flexible
Double Screw 5mm PP Strap Production Line With Long Length And Flexible
Double Screw 5mm PP Strap Production Line With Long Length And Flexible Double Screw 5mm PP Strap Production Line With Long Length And Flexible Double Screw 5mm PP Strap Production Line With Long Length And Flexible Double Screw 5mm PP Strap Production Line With Long Length And Flexible Double Screw 5mm PP Strap Production Line With Long Length And Flexible

Large Image :  Double Screw 5mm PP Strap Production Line With Long Length And Flexible

Product Details:
Place of Origin: CHINA
Brand Name: JIATUO CHINA
Certification: IS CEO
Model Number: JTPP
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: plastic film
Delivery Time: 30-40days
Payment Terms: L/C, T/T

Double Screw 5mm PP Strap Production Line With Long Length And Flexible

Description
Strap Color: Single/Multi-Color Strap Speed: >250m/min
Strap Core Diameter: 406*150mm / 200*180mm Strap Thickness: 0.4-1.2mm
Strap Tension: Adjustable Strap Width: 5-19mm
Power Supply: 380V/220V Exchange Filter: Fully Automatic
Screw Size: Single And Double Screw Production Capacity: 2.8T-12T/24hours
Highlight:

Flexible PP Strap Production Line

,

5mm PP Strap Production Line

,

Double Screw PP Strap Production Line

Double Screw 5mm PP Strap Production Line with Long Length and Flexible


Parameter of PP belt extrusion line

EModel JT-PP90 JT-PP110 JT-PP125
Productivity 100-125kg/h 280-300kg/h 360-380kg/h
Drive Motor 22kw 30kw 55kw
Two-station Winder 260m/min,adjustable
Strap Size Width:5mm-20mm Width:5mm-20mm Width:5mm-20mm
Thickness:0.4mm-1.2mm Thickness:0.4mm-1.2mm Thickness:0.4mm-1.2mm
Installed Capacity about40kw about 60kw about80kw
Line Dimension 26m×2m×2.2m (L×W×H) 26m×3m×3m (L×W×H) 26m×5m×3.5m (L×W×H)

Process flow of PP packing belt production line

Feeding → stirring → pre-drying → melting and measuring extrusion → embryo (belt embryo) cooling and forming → oven preheating → primary stretching → secondary stretching → embossening → oven tempering and setting → cooling → finished product winding


We can printing the information on strap, if need it should be add printing machine before embossing machine


Double Screw 5mm PP Strap Production Line With Long Length And Flexible 0
General Description of PP strap making line

PP baling tape production line is used to produce mechanical or manual baling tapes made of 100% PP recycled granules or new raw material. This kind of straps are widely used for packing in mining, daily necessities, textile, electrical equipment, instruments, construction, medicine etc. For our machine can product high capacity and length which can saving cost and more profits



Advantages of PP stripping

Customizable Options: This PP strap production line offers customizable color options, allowing customers to tailor the product to their specific needs, as requested by "you" who require a unique branding or color scheme.
Wide Range of Applications: The product is suitable for machine packing applications, making it an ideal solution for various industries, including packaging and logistics.
High-Quality Material: The production line utilizes high-quality PP material, ensuring a durable and long-lasting strap.
Adjustable Width and Thickness: The product offers a range of widths (5~19mm) and thicknesses (0.5-0.9mm), accommodating various strapping needs.
Competitive Pricing and Availability: With a competitive price point and availability of OEM services, this product provides a cost-effective solution for businesses looking to upgrade their strapping operations.

Applications of PP strapping

Polypropylene Strapping is used for automatic strapping machine, semi-automatic strapping machine, and manual strapping machine. It is suitable for packing light weighted cartons or pallets weighing several kilograms to several hundred kilograms.



Double Screw 5mm PP Strap Production Line With Long Length And Flexible 1

FAQ

Q1:What about the payment terms?
A1:Always 30% down payment as deposit,70% balance pay before shipping.

Q2:What about the payment way?
A2:TT,L/C at sight or MIC trade assurance.

Q3:If you will send engineer coming to our factory to install and test the machines?
A3:Yes,Every set of machine we will send professional engineer to your factory and help installation and test the machines for you.

Q4:If you have CE,SGS,ISO certificate?
A4:Yes,except these,if you also need other certificates,we also can help to apply.




Double Screw 5mm PP Strap Production Line With Long Length And Flexible 2
