Factory production of PP strapping equipment PP strapping production line PP extruder for 2-12 PP straps
Product Description of PP packing belt production equipment:
High output, the finished product line speed can reach 200-350m/min.
PP strapping tape production equipment is a high-speed extruder that can produce PP strapping tape for strapping various products.
PP strapping equipment produces plastic raw materials: recycled materials or mixed new materials can be used to produce strapping tapes, and calcium carbonate can be appropriately added according to customer conditions to reduce production costs, increase product profits, and break through market competitiveness.
The 5-19mm PP strapping tape produced by the PP strapping equipment is suitable for various fully automatic unmanned strapping machines at home and abroad.
The PP strapping equipment has high output and low power consumption, and the finished product line speed can reach 220-300m/min.
PP strapping equipment parameters
| Model |
PP-2 |
PP-4 |
PP-6 |
PP-8 |
PP-10 |
PP-12 |
| Raw material |
PP polypropylene new material/recycled material |
| Number of tapes |
2 |
4 |
6 |
8 |
10 |
12 |
| Width(mm) |
5-19 |
5-19 |
5-19 |
5-19 |
5-19 |
5-19 |
| Thickness(mm) |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
| Line speed(m/min) |
>=260-300 |
| PLC control system |
PLC |
PLC |
PLC |
PLC |
PLC |
PLC |
| Screw Model |
90 |
110 |
125 |
135 |
135 |
135 |
| Reducer model |
200 |
220 |
250 |
280 |
280 |
280 |
| Drying barrel (kg) |
100 |
150 |
200 |
200 |
200 |
200 |
| Winding machine |
Automatic winding machine /Semi-automatic winding machine |
| Screen Changer |
Automatic/Manua |
| Production capacity 24H |
2.5-3T |
6-7T |
8-9T |
10-11T |
12-13T |
13--14T |
Process flow of PP packing belt production line
The cooling system of the PP strapping production line adopts a circulating water source, a unique circulating cooling process, and multiple sets of shaping guide rails, which make the strapping cooling, shrinking and shaping more fully, the product more stable, and the size more accurate.
The oven part of the PP strapping production line adopts a hot air circulation method, with six heating tubes inside, and a unique oven hot air circulation method, which makes full use of heat energy to reduce power loss, and high-temperature resistant silicone seals to keep the oven super tight.
Applications of PP packing belt production equipment:
PP packaging belt manufacturing machine is the use of PLC touch screen control the whole machine, simple operation, Arabic data display, Chinese/English operation screen.
The PP strapping tape equipment adopts a high-efficiency extruder, quantitative extrusion, and high production capacity to ensure fast and continuous production. It can be powered off 24 hours a day and can change the net without stopping. It can be used for continuous net changing and can produce 2-12 PP tapes at the same time.
(1)Special single/double screw extrusion technology.
(2) Process 100% recycled PET material or bottle flakes material
(3) Even plasticization and stable extrusion with PLC automatic control for the full line.
(4) Melt filter with two pistons with air venting design and back flushing.
Support and Services of PP packing belt production equipment:
We provide comprehensive technical support and service for our PP Strap Making Machine. Our team of experienced technicians can provide a variety of services, including:
Pre-sales:
1.Layout plan of PP belt making machine.
2.Analysis of the cost of PP tape making machine.
3.Raw materials that can be used for PP tape making machine.
After-sales service:
1.Water and electricity circuits of PP belt making machine, circuit drawings, etc.
2.Installation, commissioning and training of PP belt making machine.
3.Maintenance service of PP belt making machine.
4.Regular maintenance and repair
5.Troubleshooting and diagnosis
6.Software updates and upgrades
7.Spare parts and accessories
8.Training and technical advice
FAQ:
Q:What is the voltage of PP strapping equipment?
A:380V/50HZ, we support customization
Q:Can the PP strapping production equipment be customized according to the factory length?
A:Yes, we can customize the length according to the customer's factory size.
Q:Where is the PP strapping equipment produced?
A:We are from China.
Q:Can PP strapping equipment provide after-sales service?
A:Yes, we have professional after-sales engineers who provide 24-hour online guidance.
Q:Is the quality of PP strapping equipment stable?
A:We have 30 years of manufacturing experience, and have their own PP packaging belt production plant, equipment quality is stable, the process is worth choosing.
Q:Does PP strapping equipment support customization?
A:We are a manufacturing plant that can customize model size, extrusion capacity, voltage and so on according to customer requirements.
