12mm Width PP Strap Making Machine for Durable Packing Belt Production Line

12mm Width PP Strap Making Machine for Durable Packing Belt Production Line
12mm Width PP Strap Making Machine for Durable Packing Belt Production Line
12mm Width PP Strap Making Machine for Durable Packing Belt Production Line 12mm Width PP Strap Making Machine for Durable Packing Belt Production Line 12mm Width PP Strap Making Machine for Durable Packing Belt Production Line 12mm Width PP Strap Making Machine for Durable Packing Belt Production Line 12mm Width PP Strap Making Machine for Durable Packing Belt Production Line 12mm Width PP Strap Making Machine for Durable Packing Belt Production Line 12mm Width PP Strap Making Machine for Durable Packing Belt Production Line 12mm Width PP Strap Making Machine for Durable Packing Belt Production Line 12mm Width PP Strap Making Machine for Durable Packing Belt Production Line 12mm Width PP Strap Making Machine for Durable Packing Belt Production Line

Large Image :  12mm Width PP Strap Making Machine for Durable Packing Belt Production Line

Product Details:
Place of Origin: Shenzhen, China
Brand Name: JIATUO
Certification: CE, ISO
Model Number: PP-2
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plastic film or other standard package for sea shipping
Delivery Time: 50~55 working days
Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability: 50set/month
Contact Now

12mm Width PP Strap Making Machine for Durable Packing Belt Production Line

Description
Product Type: 12mm Width Plastic Pet/PP Packing Strap Extruder Production Line Packing Belt Making Machine Raw Material: Polypropylene PP Raw Material Pellets, Recycled Pellets
Screw Design: Optional Processing Type: Extruding Machine
Twin Screw Type: Co-rotating Parallel Twin-screw Equipment Power: 100KW
Output: 200KG Per Hour Driven Type: Electric
Application: Packaging Strap Automation: Automatic
Warranty: 1 Year Voltage: Three-phase 380v/50Hz
Highlight:

12mm Width PP Strap Making Machine

,

Durable PP Strap Making Machine

,

Packing Belt PP Strap manufacturing Machine

12mm Width Plastic Pet/PP Packing Strap Extruder Production Line Packing Belt Making Machine




DESCRIPTION ABOUT PP STRAP MAKING MACHINE


1. Total equipment power: 100KW
2. Equipment footprint: 38*2.0*4.0M
3. Capacity: 200kg per hour
4. The equipment voltage is: three-phase 380v/50Hz
5. Equipment bearing TR brand
6. Intelligent temperature control instruments, heating solid state relays, tachometers, counters, and code counters adopt Taiwan Yangming brand, and switches and AC contactors are equipped with Schneider brand.
7. All shafts are heat treated and grinder finished
8. The fuselage frame adopts 100*100*2.5 mm (pass national standard square)

The appearance of the whole machine has been optimized and designed, which is beautiful, high-quality and high-grade, and is durable.



Model JTPP-90 JTPP-110
Extruder Model single screw 2 straps single screw 4 straps
Main Motor Power 80KW 100KW
Overall Size 30*2.0*4.0M 38*2.0*4.0M
Output 100KG/H 200KG/H
Voltage 220V/60Hz 380V/50Hz



12mm Width PP Strap Making Machine for Durable Packing Belt Production Line 0

12mm Width PP Strap Making Machine for Durable Packing Belt Production Line 1



Model No. PP-2 PP-3 PP-4 PP-6 PP-8 PP-2-2 PP-2-4
Production material PP Recycled /
raw material		 PP Recycled /
raw material		 PP Recycled /
raw material		 PP Recycled PP Recycled PP Recycled PP Recycled
Number of tapes 2 3 4 6 8 4 6
Outgoing bandwidth
(mm)		 5~19 5~19 5~19 9~19 9~19 9~19 9~19
Outlet thickness
(mm)		 0.4-1.2 0.4-1.2 0.4-1.2 0.4-1.2 0.4-1.2 0.4-1.2 0.4-1.2
Extrusion capacity
(kg/h)		 120 180 240 360 480 120 240
Maximum linear speed
(m/min)
≥250
≥250
≥250
≥250
≥250
≥250
≥250
PLC control system PLC control PLC control PLC control PLC control PLC control PLC control PLC control
Screw model 90 100 110 125 135 90/65 110/75
Reducer model 200 200 225 250 280 200/173 225/173
Automatic dryer hopper 100KG 100KG 150KG 200KG 250KG 100/100KG 100/150KG
Screen changer Manual / Auto Manual / Auto Manual / Auto Manual / Auto Manual / Auto Manual / Auto Manual / Auto
Production capacity/24H 2.8 tons 4.3 tons 5.7 tons 8.6 tons 11.5 tons 2.8 tons 5.7 tons



RANGE & MACHINE PARTS

Production Range


PET sheet application : food packaging, toys, boxes, stationery, gift boxes and hand tools, metal packaging.
Antistatic Usage : electronic parts packaging.
General purpose : folding boxes, clothing lining collar, credit card sheet, printing tape, tape-mold labels.

PET sheet specifications:
0.2, 0.25, 0.3, 0.4, 0.5, 0.8, 1.0mm-915*1220mm



Machine Parts


1. PET Non-crystallization extruding system :The newest screw thread unit, low power consumption, high output, is suitable for PET sheet extruding.

2. Three roller calender: The high-precision three roller calender forming system, with servo control, hydraulic compress structure, is cuitable for the stable extrusion of sheet thickness at 0.15mm.

3. Precision die system:Can choose the self-regulation die to realize the change between extrusion mode and casting mode, is suitable for the sheet with different thickness.

4. Automatic rolling & cutting device:Easy to adjust, cuting straightness is high.Thickness:0.8-10mm,width:800-2000mm


12mm Width PP Strap Making Machine for Durable Packing Belt Production Line 2
