Product Details:
Place of Origin: Shenzhen, China
Brand Name: JIATUO
Certification: CE, ISO
Model Number: JTPP-110
Document: parameter details of PP Str...ne.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plastic film or other standard package for sea shipping
Delivery Time: 50~55 working days
Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability: 50set/month
Contact Now

Plastic extruder PP strapping production line PP strapping machine PP plastic strapping equipment for 100-300m/min line speed

Description
Product Type: PP Packing Belt Extrusion Line Raw Material: Polypropylene PP Raw Material Pellets, Recycled Pellets
Screw Design: 1 To 4 Processing Type: Extruding Machine
Capacity: 200kg/h Power: 100KW
Driven Type: Electric Application: Packaging Strap
Automation: Automatic Warranty: 1 Year

Plastic extruder PP strapping production line PP strapping machine PP plastic strapping equipment for 100-300m/min line speed



PRODUCT DESCRIPTION



Extrusion----Extrusion capacity can be customized according to customer requirements, and can produce 2-12 strips.

Oven-----Energy-saving and environmentally friendly, constant temperature oven, high output, low power consumption.

Winding machine-----Can be equipped with semi-automatic winding machine & fully automatic winding machine according to customer requirements


Polypropylene strapping is the most economical of all strapping material due to it's light weight and versatility.it is available in a wide variety of sizes and gauges and offers the greatest elongation of any strapping type,along with good initial recovery characteristics.polypropylene can be heat sealed with joint efficiency of 70 to 80%.



PP strapping production line 1 to 4 product parameters:

Name: PP 1 to 4 strapping production line

Model number: JTPP-110

Applicable raw materials: New PP particles, PP recycled materials, PP crushed materials

Number of screws: 1 Screw

Number of extruded belts: 4

Width range: 5-19mm

Thickness range: 0.4-1.2mm

Production capacity: 200-250kg/h

Installation size: L38*W2.0*H4.0(m)



Model No. Screw Size No. of strap Capacity Total Power Width  Thickness Installation Dimensions
JTPP-90 2800mm 2 100kg/h 80kw 5-19mm 0.4-1.2mm 30*2.0*4.0M
JTPP-100 2800mm 3 150kg/h 90kw 5-19mm 0.4-1.2mm 30*2.2*4.0M
JTPP-110 3300mm 4 200kg/h 100kw 5-19mm 0.4-1.2mm 38*2.0*4.0M
JTPP-125 3700mm 6 200-250kg/h 110kw 5-19mm 0.4-1.2mm 40*2.0*4.0M



The process flow of PP Packing Strap Belt Making Machine:

Vacuum feeding → Dryer → Extruding system → High speed Net exchanging system → Mould → Water cooling system →

Traction rollers → Stretch oven 1 → Tensile unit→ Embossing unit → Tensile unit→ Double winder



Plastic extruder PP strapping production line PP strapping machine PP plastic strapping equipment for 100-300m/min line speed 0

Features of PP strapping equipment

High degree of automation----- reduce manual intervention, improve efficiency, PLC control, easy debugging.

High production efficiency----- continuous production, large output, 24-hour non-stop production.

Stable product quality----- automated control ensures consistency of extrusion specifications, suitable for high-end strapping machines.


Plastic extruder PP strapping production line PP strapping machine PP plastic strapping equipment for 100-300m/min line speed 1

  • Company advantages:

    Our company has more than 30 years of experience in strapping equipment manufacturing in China. We have a professional R&D team, sales team, production plant, imported processing equipment from Germany, and technical personnel often go abroad for further study and learning. We have more than 50 patented products. In China's strapping packaging industry, our company has a good reputation, advanced technology, and high-end products, and always ranks first. We can provide customers with better equipment and produce higher-end products.

    Currently: We have our own

    PP strapping production factory: 1 PCS

    PET strapping production factory: 2, PCS

    PP PET strapping equipment manufacturing factory: 1PCS

    We are fully aware of the formula ratio of various raw materials, the equipment ratio of various parameters, and the technical parameters of the strapping tapes required by our customers during the production process.


Plastic extruder PP strapping production line PP strapping machine PP plastic strapping equipment for 100-300m/min line speed 2
