5-19mm Width PP Strap Making Machine Extrusion Line 200kg/H

Large Image : 5-19mm Width PP Strap Making Machine Extrusion Line 200kg/H

Product Details:

Place of Origin:	Shenzhen, China
Brand Name:	JIATUO
Certification:	CE, ISO
Model Number:	JTPP-110

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Negotiable
Packaging Details:	plastic film or other standard package for sea shipping
Delivery Time:	50~55 working days
Payment Terms:	L/C,D/A,T/T,Western Union,MoneyGram
Supply Ability:	50set/month

Contact Now

5-19mm Width PP Strap Making Machine Extrusion Line 200kg/H

Description

Product Type:	PP Packing Belt Extrusion Line	Raw Material:	Polypropylene PP Raw Material Pellets, Recycled Pellets
Screw Design:	1 To 6	Processing Type:	Extruding Machine
Capacity:	130kg/h	Power:	100KW
Driven Type:	Electric	Application:	Packaging Strap
Automation:	Automatic	Warranty:	1 Year
Highlight:	19mm Width PP Strap Making Machine , 19mm Width pp strap extrusion line , pp strap extrusion line 200kg/H

5-19mm Width PP Strap Making Machine Band Extruder 200kg/h Max Capacity

PRODUCT DESCRIPTION

PP strapping production line 1 to 6 product parameters:

Name: PP 1 to 6 strapping production line

Model number: JTPP-110

Applicable raw materials: New PP particles, PP recycled materials, PP crushed materials

Number of screws: 1 Screw

Number of extruded belts: 6

Width range: 5-19mm

Thickness range: 0.4-1.2mm

Production capacity: 130kg/h

Installation size: L38*W2.0*H4.0(m)

Model No.	Screw Size	No. of strap	Capacity	Total Power	Width Range	Thickness Range	Installation Dimensions
JTPP-90	2800mm	2	100kg/h	80kw	5-19mm	0.4-1.2mm	302.04.0M
JTPP-100	2800mm	3	150kg/h	90kw	5-19mm	0.4-1.2mm	302.24.0M
JTPP-110	3300mm	4	200kg/h	100kw	5-19mm	0.4-1.2mm	382.04.0M
JTPP-110	3300mm	6	130kg/h	100kw	5-19mm	0.4-1.2mm	382.04.0M

The process flow of PP Packing Strap Belt Making Machine:

Vacuum feeding → Dryer → Extruding system → High speed Net exchanging system → Mould → Water cooling system →

Traction rollers → Stretch oven 1 → Tensile unit→ Embossing unit → Tensile unit→ Double winder

5-19mm Width PP Strap Making Machine Extrusion Line 200kg/H 0

Plastic Strapping

Plastic strappping materials are made from Polyester,Polypropylene and are available in a variety of strengths,

styles,and finishes.Unlike steel strapping,elongation and recovery are a key factor for deciding which type of

plastic strap to use.

Polypropylene Strapping

Polypropylene strapping is an economical strapping material compared to other materials.it's designed for light to

medium duty unitizing,palletizing and bundling.Consistent pressure to polypropylene strapping can result in

unrecoverable dead stretch and inability to return to its original length

Features of PP strapping production line:

1. It is suitable for all levels of recycled plastic particles, and produces sandwich belts and PP environmentally friendly packing belts;

2. It can be used to directly produce manual packing belts;

3. It can also be directly processed into hand-use, machine-use, printing packing tape, ultra-wide, ultra-thin, ultra-narrow, transparent, dyeing, and printing PP packing tape;

4. It is currently the most cost-effective and competitive product on the market, and is popular among small and medium-sized investors;

5. It can produce all kinds of manual belts, machine-use PP packing belts and export belts.

5-19mm Width PP Strap Making Machine Extrusion Line 200kg/H 2
