Product Details:
Place of Origin: Shenzhen, China
Brand Name: JIATUO
Certification: CE, ISO
Model Number: JTPP-100
Document: parameter details of PP Str...ne.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plastic film or other standard package for sea shipping
Delivery Time: 30~55 working days
Payment Terms: L/C, D/A, T/T,
Supply Ability: 50set/month

Supply PP strapping production line PP strapping machine PP strapping equipment with PLC control system

Description
Product Type: PP Packing Belt Extrusion Line Raw Material: Polypropylene PP Raw Material Pellets, Recycled Pellets
Screw Design: 1 To 4 Processing Type: Extruding Machine
Capacity: 200-250kg/h Power: 100KW
Twin Screw Type: Co-rotating Parallel Twin-screw Application: Packaging Strap
Automation: Automatic Warranty: 1 Year
Highlight:

Polypropylene PP Strap Making Machine

,

80KW strapping roll manufacturing machine

,

80KW Strapping Roll Manufacturing Machine

Supply PP strapping production line PP strapping machine PP strapping equipment with PLC control system



PRODUCT DESCRIPTION



PP strapping production line 1 to 3 product parameters:

Name: PP 1 to 4 strapping production line

Model number: JTPP-100

Applicable raw materials: New PP particles, PP recycled materials, PP crushed materials

Number of screws: 1 Screw

Number of extruded belts: 4

Width range: 5-19mm

Thickness range: 0.5-1.5mm

Production capacity: 200-250kg/h

Installation size: L36*W2.0*H4.0(m)



                                              Extrusion Capacity Comparison Table

Model No. Screw Size No. of strap Capacity Total Power Width  Thickness  Installation Dimensions
JTPP-90 2800mm 2 100kg/h 80kw 5-19mm 0.4-1.2mm 30*2.0*4.0M
JTPP-100 2800mm 3 120kg/h 90kw 5-19mm 0.4-1.2mm 30*2.2*4.0M
JTPP-110 3300mm 4 200kg/h 100kw 5-19mm 0.4-1.2mm 38*2.0*4.0M
JTPP-120 3700mm 6 300kg/h 120kw 5-19mm 0.4-1.2mm 40*2.0*4.0M



Supply PP strapping production line PP strapping machine PP strapping equipment with PLC control system 0

Features:​


PP plastic strapping machine is a high-end equipment used to produce PP strapping for a wide range of uses.

Raw materials------100% polypropylene new material or recycled material

Control method------ PLC control system, which can be set to different languages.

Motor------The equipment is driven by Siemens motor, which has stable and reliable performance and low failure rate.

Line speed------ 200-300 m/min

Features of embossing wheel:

1. The embossing wheel is nitrided and heat-treated to achieve a surface hardness of 60 degrees, which is strong and durable. The surface texture of the strapping tape pressed out by this embossing machine is clear and rough enough, and the automatic strapping machine uses strong belt feeding.

2. The upper and lower flower wheels of the embossing machine are equipped with synchronous gears to ensure synchronous rotation of the upper and lower wheels, ensuring that the flower spinning on both sides of the strapping tape is completely consistent, increasing the beauty and transparency of the strapping tape.

3. When assembling the upper and lower flower wheels, a fixed gap is left to prevent collision, which extends the service life of the flower wheels

Supply PP strapping production line PP strapping machine PP strapping equipment with PLC control system 1



About After-sales

We provide comprehensive technical support and service for our PP Strap Making Machine. Our team of experienced technicians can provide a variety of services, including:

Pre-sales:

1.Layout plan of PP belt making machine.

2.Analysis of the cost of PP tape making machine.

3.Raw materials that can be used for PP tape making machine.

After-sales service:

1.Water and electricity circuits of PP belt making machine, circuit drawings, etc.

2.Installation, commissioning and training of PP belt making machine.

3.Maintenance service of PP belt making machine.

4.Regular maintenance and repair

5.Troubleshooting and diagnosis

6.Software updates and upgrades

7.Spare parts and accessories

8.Training and technical advice



FQA:



Q:What is the voltage of PP strapping equipment?
A:380V/50HZ, we support customization
Q:Can the PP strapping production equipment be customized according to the factory length?
A:Yes, we can customize the length according to the customer's factory size.
Q:Where is the PP strapping equipment produced?
A:We are from China.
Q:Can PP strapping equipment provide after-sales service?
A:Yes, we have professional after-sales engineers who provide 24-hour online guidance.
Q:Is the quality of PP strapping equipment stable?
A:We have 30 years of manufacturing experience, and have their own PP packaging belt production plant, equipment quality is stable, the process is worth choosing.
Q:Does PP strapping equipment support customization?
A:We are a manufacturing plant that can customize model size, extrusion capacity, voltage and so on according to customer requirements.
