PET strap making machine PET strapping production equipment with extrusion output of 200-600KG/H

PET strap making machine PET strapping production equipment with extrusion output of 200-600KG/H

PRODUCT DESCRIPTION OF PET STRAP MAKINGE MACHINE


PET strap making machine /PET plastic strapping production equipment is specialized for producing high-strength, environmentally friendly PET plastic strapping. Its key features include:

1. Efficient and Automated Production

Continuous Production------ PET equipment utilizes an integrated process for extrusion, cooling, stretching, shaping, and winding, resulting in a high degree of automation and high production efficiency, making it suitable for large-scale production.

Intelligent Control------- A PLC (Programmable Logic Controller) and touchscreen human-machine interface enable precise control of parameters (such as temperature, tension, and speed), minimizing manual intervention.

Quick Mold Change-------- Some equipment supports quick mold changes, enabling flexible production of plastic strapping in various widths (e.g., 9mm--25mm) and thicknesses. This is convenient and hassle-free.

KEY FEATURES:

Dedicated PET Screw------Features powerful plasticization and high extrusion output; compatible with both PET bottle flakes and recycled materials, ensuring a uniform and stable melt.

Intelligent Temperature Control------ Equipped with an intelligent constant-temperature system featuring real-time data display; prevents raw material scorching caused by excessive heat, thereby maintaining premium product quality.

Precise Stretching------ Achieves a stretching ratio of 4.5–6.5 times, resulting in highly oriented molecular chains, superior tensile strength, high fracture resistance, and excellent aging resistance.

Tension Control------- Utilizes high-precision tension sensing throughout the entire process to ensure uniform strap thickness, minimal dimensional tolerance, no lateral deviation, and no slackness, delivering exceptional toughness.

                                             EXTRUSION PARAMETERS TABLE




Regarding the raw materials for PET tape making machines:


Raw Materials-----PET bottle flakes / polyester granules, or crushed PET scrap.

FEATURES:

Compatible with production utilizing 100% recycled materials. The entire production line integrates core units such as pre-crystallization and drying, specialized screw extrusion, rapid hydraulic screen changing, precision die heads, multi-stage oven stretching, shaping, embossing, and dual-station automatic winding. This enables fully automated, continuous, and high-speed production—from raw materials to finished strapping bands—and is managed by a PLC control system, thereby reducing manufacturing costs.

PET strapping production line process flow

① Loading →② Mixing raw materials →③ Pre-drying raw materials →④ Vacuum dehumidification of raw materials →⑤ Melting and metering extrusion of raw materials →⑥ Cooling and forming of raw materials (with raw materials) →⑦ Preheating the oven →⑧ Primary stretching →⑨ Secondary stretching →⑩ Embossing →⑪ Oven tempering and shaping →⑫ Cooling →⑬ Finished product winding


FAQ:

Q: What is the voltage of the PET strap making machine?
A: 380V/50HZ, three-phase (customization supported)
Q: What is the extrusion capacity of the PET strap making machine?
A: Different models have different extrusion capacities, with capacities ranging from 150-600KG/H
Q: What is the producible width of the PET strap making machine?
A: 9-32mm
Q: Can the PET strap making machine be customized?
A: Customization supported
Q: Where does the PET strap making machine come from?
A: China.
Q: What are the certifications for the PET strap making machine?
A: ISO CEO certification.
Q: What is the minimum order quantity for the PET strap making machine?
A: 1 set
Q: What is the weight of the PET strap making machine?
20T, 40GP container * 3PCS
