PP Strapping Production Line 5-19mm PP Strapping Equipment PP Strap Band Extrusion Line
DESCRIPTION OF PP PACKING BELT MAKING MACHINE
PP packing belt making machine is a high-speed extruder that can produce PP strapping band for strapping various products.
PP packing belt making machine is a mechanical equipment used to manufacture polypropylene (PP) strapping tape. It is widely used in the packaging industry and has more advantages:
High degree of automation----PP packing belt making machine adopts high-speed automation design, PLC control, simple operation and convenient debugging.
High production efficiency----high speed, continuous production, line speed can reach 200-300 meters/minute.
Stable product quality---Automation control ensures stable product quality, with more than 30 years of experience in manufacturing PP packing belt making machine.
Energy saving and environmental protection----PP packing belt making machine adopts energy-saving motors and circulating cooling water systems to reduce energy consumption and pollution.
Raw material:
----------- PP Polypropylene Granules
----- Accounting for over 95% of the total material, PP is the core raw material for strapping tape.
----- Features: Lightweight, wear-resistant, corrosion-resistant, high tensile strength, and low cost.
EXTRUSION PARAMETERS TABLE
| Model |
PP-2 |
PP-4 |
PP-6 |
PP-8 |
PP-10 |
PP-12 |
| Raw material |
PP polypropylene new material/recycled material |
| Number of tapes |
2 |
4 |
6 |
8 |
10 |
12 |
| Width(mm) |
5-19 |
5-19 |
5-19 |
5-19 |
5-19 |
5-19 |
| Thickness(mm) |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
| Line speed(m/min) |
≧260-300 |
| PLC control system |
PLC |
PLC |
PLC |
PLC |
PLC |
PLC |
| Screw Model |
90 |
110 |
125 |
135 |
135 |
135 |
| Reducer model |
200 |
220 |
250 |
280 |
280 |
280 |
| Winding machine |
Automatic winding machine /Semi-automatic winding machine |
| Screen Changer |
Automatic/Manua |
| Production capacity 24H |
2.5-3T |
6-7T |
8-9T |
10-11T |
12-13T |
13--14T |
DETAILS OF PP PACKING BELT MAKING MACHINE
Screen changer--------
Four-net circulation large-area filter screen, 24-hour non-stop screen change, reducing manual operations and advancing production capacity.
Auxiliary Feeding Section:
The PP strapping equipment is equipped with ---- 3 sets of auxiliary feeders,
Can add dyeing masterbatch------- change the color of PP strap
Can add filling masterbatch----- reduce the cost of PP strap by more than 30%
Can add defoaming agent-------- eliminate the moisture of PP raw materials
Applicable to balers:
1. Fully automatic baler
2. High-speed baler
3. Semi-automatic baler
4. Handheld electric baler
5. Manual clamp baler
FQA:
Q:What is the voltage of PP packing belt making machine ?
A:380V/50HZ, we support customization
Q:Can the PP packing belt making machine be customized according to the factory length?
A:Yes, we can customize the length according to the customer's factory size.
Q:Where is the PP packing belt making machine?
A:We are from China.
Q:Can PP packing belt making machine provide after-sales service?
A:Yes, we have professional after-sales engineers who provide 24-hour online guidance.
Q:Is the quality of PP packing belt making machine stable?
A:We have 30 years of manufacturing experience, and have their own PP packing belt making machine plant, equipment quality is stable, the process is worth choosing.
Q:Does PP packing belt making machine customization?
A:We are a manufacturing plant that can customize model size, extrusion capacity, voltage and so on according to customer requirements.
