Packaging machinery Twin screw PP strapping equipment PP strapping production line with 150-300 m/min

Packaging machinery Twin screw PP strapping equipment PP strapping production line with 150-300 m/min
Packaging machinery Twin screw PP strapping equipment PP strapping production line with 150-300 m/min Packaging machinery Twin screw PP strapping equipment PP strapping production line with 150-300 m/min Packaging machinery Twin screw PP strapping equipment PP strapping production line with 150-300 m/min Packaging machinery Twin screw PP strapping equipment PP strapping production line with 150-300 m/min

Large Image :  Packaging machinery Twin screw PP strapping equipment PP strapping production line with 150-300 m/min

Product Details:
Place of Origin: Shenzhen, China
Brand Name: JIATUO
Certification: CE, ISO
Model Number: JTPP-110
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plastic film or other standard package for sea shipping
Delivery Time: 50~55 working days
Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability: 50set/month

Packaging machinery Twin screw PP strapping equipment PP strapping production line with 150-300 m/min

Description
Product Type: PP Packing Belt Extrusion Line Raw Material: 100% PP
Screw Design: Optional Twin Screw Type: Co-rotating Parallel Twin-screw
Driven Type: Electric Processing Type: Extruding Machine
Automation: Automatic Application: Packaging Strap
Width: 5-19mm Thickness: 0.4-1.2mm
Highlight:

Packaging Machinery PP Strapping Production Line

,

Packaging Machinery PP Strapping Equipment

Packaging machinery Twin screw PP strapping equipment PP strapping production line with 150-300 m/min

Quick Detail Of PP Strap Making Machine



PP strapping equipment:

PP strapping equipment produces plastic

Raw materials:

1.recycled materials or mixed new materials can be used to produce strapping tapes, and calcium carbonate can be appropriately added according to customer conditions to reduce production costs, increase product profits, and break through market competitiveness.

2. The 5-19mm PP strapping tape produced by the PP strapping equipment is suitable for various fully automatic unmanned strapping machines at home and abroad.

3. The PP strapping equipment has high output and low power consumption, and the finished product line speed can reach 220-300m/min.

PP strapping equipment can be equipped with automatic winding machine or semi-automatic winding machine.



Features of the oven:

1. There is a high-power heating tube inside the oven, and the hot air circulation method makes full use of heat energy to reduce power loss.

2. High-temperature resistant silicone seals keep the oven super tight

3. Special high-efficiency all-stainless steel electric heating tube, fast heating, long-lasting and durable

4. Reheating makes the PP strapping tape shrink in the oven, and the straightness of the strapping tape produced is more standardized and the shrinkage rate is smaller.



                                           EXTRUSION PARAMETERS TABLE

Model PP-2 PP-4 PP-6 PP-8 PP-10 PP-12
Raw material PP polypropylene new material/recycled material
Number of tapes 2 4 6 8 10 12
Width(mm) 5-19 5-19 5-19 5-19 5-19 5-19
Thickness(mm) 0.4-1.2 0.4-1.2 0.4-1.2 0.4-1.2 0.4-1.2 0.4-1.2
Line speed(m/min)                         ≧260-300
PLC control system PLC PLC PLC PLC PLC PLC
Screw Model 90 110 125 135 135 135
Reducer model 200 220 250 280 280 280
Winding machine Automatic winding machine /Semi-automatic winding machine
Screen Changer Automatic/Manua
Production capacity 24H 2.5-3T 6-7T 8-9T 10-11T 12-13T 13--14T

Packaging machinery Twin screw PP strapping equipment PP strapping production line with 150-300 m/min 0




The main components of PP strapping equipment:



Extrusion----Extrusion capacity can be customized according to customer requirements, and can produce 2-12 strips.

Oven-----Energy-saving and environmentally friendly, constant temperature oven, high output, low power consumption.

Winding machine-----Can be equipped with semi-automatic winding machine & fully automatic winding machine according to customer requirements



 Finished PP belt:

Packaging machinery Twin screw PP strapping equipment PP strapping production line with 150-300 m/min 1



About us:

We have more than 30 years of manufacturing experience in the PP/PET strapping industry, and our R&D and after-sales personnel often go abroad to study;

We are a manufacturing factory with our own production workshop, and all accessories are processed by our own lathes.

We have our own production team, R&D team, after-sales team, sales team, etc.

The quality of the machines we produce is stable and the after-sales service is guaranteed.



Packaging machinery Twin screw PP strapping equipment PP strapping production line with 150-300 m/min 2

FAQ About PP Belt Strapping Production Line


Q:What is the voltage of PP strapping equipment?
A:380V/50HZ, we support customization
Q:What is the length of the PP strapping tape??
A: L:36 M.
Q:Where is the PP strapping equipment produced?
A:We are from China.
Q:Can PP strapping equipment provide after-sales service?
A:Yes, we have professional after-sales engineers who provide 24-hour online guidance.
Q:Is the quality of PP strapping equipment stable?
A:We have 30 years of manufacturing experience, and have their own PP packaging belt production plant, equipment quality is stable, the process is worth choosing.
Q:Does PP strapping equipment support customization?
A:We are a manufacturing plant that can customize model size, extrusion capacity, voltage and so on according to customer requirements.

Q:What does the wrapping machine part of the PP strapping equipment look like?

A:Equipped with automatic wrapping machine/semi-automatic wrapping machine.
