Product Details:
Place of Origin: Shenzhen, China
Brand Name: JIATUO
Certification: CE, ISO
Model Number: JTPP-110
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plastic film or other standard package for sea shipping
Delivery Time: 50~55 working days
Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability: 50set/month
Contact Now

Packaging machinery Twin screw sandwich PP strapping equipment Double layer PP strapping machine PP strapping production line with automatic screen changer

Description
Product Type: PP Packing Belt Extrusion Line Raw Material: 100% PP
Screw Design: Optional Twin Screw Type: Co-rotating Parallel Twin-screw
Driven Type: Electric Processing Type: Extruding Machine
Automation: Automatic Application: Packaging Strap
Width: 5-19mm Thickness: 0.4-1.2mm
Highlight:

Twin Screw PP Strapping Equipment

,

Packaging Machinery PP Strapping Equipment

,

PP Strapping Production Line

Packaging machinery Twin screw sandwich PP strapping equipment Double layer PP strapping machine PP strapping production line with automatic screen changer

Quick Detail Of PP Strap Making Machine



PP strapping equipment:

Main types: can be divided into semi-automatic strapping machine and fully automatic strapping machine.



Semi-automatic baler------requires manual feeding of packaging materials and goods, and automatically completes the baling process.



Fully automatic baler-------can realize a series of operations such as automatic feeding, baling, and cutting, with higher efficiency, and can automatically use electric heat welding technology for baling.



About the screen changing system of PP strapping equipment:





PP strapping equipment can be equipped with an automatic screen changer or a manual screen changer.

The automatic screen changer does not require downtime to replace the filter, and can produce continuously for 24 hours.

The manual screen changer requires downtime to replace the filter, and the process takes about 30 minutes/time



                                           EXTRUSION PARAMETERS TABLE

Model PP-2 PP-4 PP-6 PP-8 PP-10 PP-12
Raw material PP polypropylene new material/recycled material
Number of tapes 2 4 6 8 10 12
Width(mm) 5-19 5-19 5-19 5-19 5-19 5-19
Thickness(mm) 0.4-1.2 0.4-1.2 0.4-1.2 0.4-1.2 0.4-1.2 0.4-1.2
Line speed(m/min)                         ≧260-300
PLC control system PLC PLC PLC PLC PLC PLC
Screw Model 90 110 125 135 135 135
Reducer model 200 220 250 280 280 280
Winding machine Automatic winding machine /Semi-automatic winding machine
Screen Changer Automatic/Manua
Production capacity 24H 2.5-3T 6-7T 8-9T 10-11T 12-13T 13--14T


 Packaging machinery Twin screw sandwich PP strapping equipment Double layer PP strapping machine PP strapping production line with automatic screen changer 0


Packaging machinery Twin screw sandwich PP strapping equipment Double layer PP strapping machine PP strapping production line with automatic screen changer 1



The main components of PP strapping equipment:



Feeder------ transfer PP raw materials into the machine.

Extruder------heat and melt the PP raw materials and extrude them into shape.

Molding mold------ make the molten PP tape embryo pass through the mold to form a strip.

Cooling water tank------cool the extruded PP tape embryo to ensure its shaping.

Tractor------pull out the cooled strapping tape to maintain a stable production speed.

Oven------ heat the strapping tape to improve its strength and toughness.

Embossing machine------ emboss the surface of the strapping tape to increase friction and prevent slipping.

Shaping oven------heat again, shape, and make the PP tape more standardized.

Reeler------ reel the strapping tape into rolls for easy storage and transportation.



                                    Specifications of PP strapping tape:



Model Width Thickness Pull Gross weight Net weight Paper core Length
PP-05045 5.0mm 0.45mm >50kg 10kg 9.5kg Ø200mm 7000m
PP-08050 8.0mm 0.50mm >90kg 10kg 9.5kg Ø200mm 4700m
PP-09060 9.0mm 0.60mm >90kg 10kg 9.5kg Ø200mm 3150m
PP-10060 10.0mm 0.60mm >110kg 10kg 9.5kg Ø200mm 2350m
PP-11045 11.0mm 0.45mm >80kg 10kg 9.5kg Ø200mm 3650m
PP-12080 12.0mm 0.80mm >150kg 10kg 9.5kg Ø200mm 1700m
PP-13580 13.5mm 0.80mm >160kg 10kg 9.5kg Ø200mm 1550m
PP-15100 15.0mm 1.00mm >180kg 10kg 9.5kg Ø200mm 1050m
PP-18080 18.0mm 0.80mm >180kg 10kg 9.5kg Ø200mm 1150m
PP-19060 19.0mm 0.60mm >160kg 10kg 9.5kg Ø200mm 1350m
PP-19070 19.0mm 0.70mm >200kg 10kg 9.5kg Ø200mm 1200m
PP-19080 19.0mm 0.80mm >240kg 10kg 9.5kg Ø200mm 1000m




About us:

We have more than 30 years of manufacturing experience in the PP/PET strapping industry, and our R&D and after-sales personnel often go abroad to study;

We are a manufacturing factory with our own production workshop, and all accessories are processed by our own lathes.

We have our own production team, R&D team, after-sales team, sales team, etc.

The quality of the machines we produce is stable and the after-sales service is guaranteed.



Packaging machinery Twin screw sandwich PP strapping equipment Double layer PP strapping machine PP strapping production line with automatic screen changer 2

FAQ About PP Belt Strapping Production Line


Q:What is the voltage of PP strapping equipment?
A:380V/50HZ, we support customization
Q:What is the length of the PP strapping tape??
A: L:36 M.
Q:Where is the PP strapping equipment produced?
A:We are from China.
Q:Can PP strapping equipment provide after-sales service?
A:Yes, we have professional after-sales engineers who provide 24-hour online guidance.
Q:Is the quality of PP strapping equipment stable?
A:We have 30 years of manufacturing experience, and have their own PP packaging belt production plant, equipment quality is stable, the process is worth choosing.
Q:Does PP strapping equipment support customization?
A:We are a manufacturing plant that can customize model size, extrusion capacity, voltage and so on according to customer requirements.

Q:What does the wrapping machine part of the PP strapping equipment look like?

A:Equipped with automatic wrapping machine/semi-automatic wrapping machine.
