Plastic machinery 9-25mm single screw PET strapping machine PET plastic steel strapping production line PET strapping equipment with PLC control system

Customer Reviews
Well received the PET strap making machine today, it's easy for installation and operation.

—— Ahmed from Sudan

Since using JIATUO strapping line, our production efficiency has increased dramatically and the equipment is running very stably!

—— Avinash from India

Excellent cooperation with Jiatuo Machinery, and thanks for Zoey's fast service. I am going to buy another one PP making machine!!!

—— Mustafa Koçak from Turkey

High production capability and low energy consumption, which can help me to make lots of money!!

—— Kashan from Pakistan

This is the second PP machine I ordered, the output is very high, the energy consumption is low, which greatly saves my production cost, thank you very much for Arey's patient guidance and service!

—— Hasseb from Columbia

JIATUO's technical team is very professional, door to door installation of our machine, a few days is exactly stable operation, thank you very much!

—— Farzed from Turkey

I'm Online Chat Now

Plastic machinery 9-25mm single screw PET strapping machine PET plastic steel strapping production line PET strapping equipment with PLC control system

Plastic machinery 9-25mm single screw PET strapping machine PET plastic steel strapping production line PET strapping equipment with PLC control system
Plastic machinery 9-25mm single screw PET strapping machine PET plastic steel strapping production line PET strapping equipment with PLC control system Plastic machinery 9-25mm single screw PET strapping machine PET plastic steel strapping production line PET strapping equipment with PLC control system Plastic machinery 9-25mm single screw PET strapping machine PET plastic steel strapping production line PET strapping equipment with PLC control system Plastic machinery 9-25mm single screw PET strapping machine PET plastic steel strapping production line PET strapping equipment with PLC control system Plastic machinery 9-25mm single screw PET strapping machine PET plastic steel strapping production line PET strapping equipment with PLC control system

Large Image :  Plastic machinery 9-25mm single screw PET strapping machine PET plastic steel strapping production line PET strapping equipment with PLC control system

Product Details:
Place of Origin: CHINA
Brand Name: JIATUO Machinery
Certification: IS CEO
Model Number: JT-PET100
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: plastic film
Delivery Time: 30-40days

Plastic machinery 9-25mm single screw PET strapping machine PET plastic steel strapping production line PET strapping equipment with PLC control system

Description
Strap Thickness: 0.4-1.2mm Model: 100*2900mm
Voltage: 380V/50HZ (customized) Raw Material: PET Bottle Flake Material, 100% Broken Material
Winding Method: Manual/automatic Total Power: 250KW(Power For Operation:120-120KW)
Power: 45KW Strap Width: 9-32mm
Capacity: 180-200kg/H Pull: 350-650kg
Highlight:

PLC control system Strapping Machine

,

9-25mm PET Strapping Machine

,

PLC Control System Plastic Machinery

Plastic machinery 9-25mm single screw PET strapping machine PET plastic steel strapping production line PET strapping equipment with PLC control system



Main description of PET strap production line :



PET pet packaging belt production line features:

1. Better tensile strength-----PET strap production line has the tensile strength of steel belt, good ductility and better impact resistance. Not easy to break, can ensure the safety of product transportation.

2. Small extension-----Although PET strap is a plastic, its extension change is very small, its elongation is only 1/6 of polypropylene, it can maintain tension, and after packaging, the expansion will no longer change.

3. Strong temperature resistance----Experiments have shown that the melting point of PET packaging belt is around 260℃, and it can be used under 120℃ for a long time without distortion, and it has good stability.

4. Good economic benefits----The density of PET packaging tape is 1.30 ~ 1.38g/cm3, which is only 1/6 of the density of steel tape (7.8g/cm3), equivalent to the length of 6 tons of steel tape, and the price of the same unit length is relatively low.

5. Environmental protection----Steel tape will rust due to exposure to air, and the permeability of rust to packaging is high. PET packaging tape is beautiful and will not rust, but it can avoid unnecessary worries. It can also be recycled.

Plastic machinery 9-25mm single screw PET strapping machine PET plastic steel strapping production line PET strapping equipment with PLC control system 0



Application of PET strap

PET packing straps are widely used as a high-performance alternative to steel straps in international packing applications. They offer excellent tensile strength, flexibility, and a low elongation rate, along with superior heat resistance, anti-rust properties, and cost efficiency.

These straps are ideal for bundling a variety of materials, including glass, steel, stone, construction materials, chemical fibers, paper, tobacco, and agricultural products, making them a versatile solution across multiple industries.



Technical parameters:


Raw material PET tackifier material or PET recycled material
Width of final product 9-32mm
thickness of final product 0.4-1.2mm
Max Capacity 300-330kg/h
Manpower 1-2 persons/shift
Machine Dimension 55*2*8m
BRANDS
Gearbox: GUOMAO
Contactor: Schneider
Temperature controller Fotek
Inverter INVT

Plastic machinery 9-25mm single screw PET strapping machine PET plastic steel strapping production line PET strapping equipment with PLC control system 1



PET plastic steel belt production line extrusion process:



Horizontal feeder ----mix different PET crushed materials or bottle flakes evenly.

Drying barrel ------ heat the PET raw materials to dry the moisture.

Dehumidifier--------remove the moisture in the PET raw materials.

Extrusion molding-------make the molten PET belt blank pass through the mold to form.

Cooling water tank-------cool the extruded PET belt blank to ensure its molding.

Tractor--------tow the cooled PET strapping belt to maintain a stable production speed.

Stretcher--------stretch the formed PET belt instantly, about 1-10 times

Oven--------heat the strapping belt to improve the toughness of the PET belt.

Embossing machine------emboss the surface of the strapping belt to increase friction and prevent slipping.

Forming oven--------heat and shape again to make the PET belt more standardized.

Rewinder---------roll the strapping belt into a roll for easy storage and transportation.



Plastic machinery 9-25mm single screw PET strapping machine PET plastic steel strapping production line PET strapping equipment with PLC control system 2



Application areas:

Packaging industry: used for packaging of various items, such as building materials, metals, paper products, etc.

Logistics industry: used for fixing and bundling during cargo transportation.

Other industries: such as home appliances, food, chemicals, etc.

Plastic machinery 9-25mm single screw PET strapping machine PET plastic steel strapping production line PET strapping equipment with PLC control system 3



FAQ

1. Are you trading company or manufacturer?
We are manufacturer, and also provide the business solution to all the friends.


2. Do you have quality certificate?
Yes we have CE, SGS etc.


3. What's the delivery time?
Around 40~50days, however, based on order.



4. What is your overseas service?
We will provide high quality overseas service ,our technical staff will be able to provide you with technical support, for you personally to overseas assembly and test equipment

Plastic machinery 9-25mm single screw PET strapping machine PET plastic steel strapping production line PET strapping equipment with PLC control system 4
