Reliable 9-25mm Pet plastic production line pet plastic steel belt equipment with automatic screen changer
Product Description of pet strap manufacturing machine:
PET strapping machine is an industrial equipment used to make polyethylene terephthalate (PET) strapping, which is widely used for packaging and strapping in various industries such as logistics, construction, steel, aluminum, chemical fiber, cotton spinning, etc.
PET strapping is a strong and environmentally friendly alternative to steel strapping and PP strapping, with its high tensile strength, flexibility and recyclability as its advantages.
Raw materials: 100% bottle flakes & PET crushed materials
Technical parameter of PET strap double output extrusion line
| Model |
PET-2 |
PET-3 |
PET-4 |
PET-6 |
PET-8 |
| Raw materials |
100% Bottle flakes/crushed materials |
| Number of tapes |
2 |
3 |
4 |
6 |
8 |
| Width (mm) |
9-32 |
| Width (mm) |
0.4-1.2 |
| Maximum line speed(m/min) |
≧150 |
≧150 |
≧150 |
≧150 |
≧150 |
| PLC control system |
PLC |
PLC |
PLC |
PLC |
PLC |
| Screw Model |
90 |
100 |
125 |
150 |
180 |
| Reducer model |
200 |
250 |
280 |
315 |
350 |
| Dryer tank |
3000L |
4000L |
5000L |
6000L |
6000L |
| Dehumidifier |
1000 |
1000 |
2000 |
3000 |
3500 |
| Metering Pumps |
100CC |
100CC |
100CC |
100CC |
100CC |
| Screen Changer |
Single cylinder |
| Winding machine |
Automatic winding/ Semi-automatic winding |
| Production capacity /24 H |
5-6T |
7-8T |
10-12T |
12-15T |
18-20T |
Basic parameters of PET steel plastic belt equipment:
Production capacity: usually 100-600 kg/hour.
Belt width: commonly 9-32 mm.
Belt thickness: usually 0.4-1.2 mm.
Equipment power: depending on the model, the power is between 100-600KW.
Different extruder models and production capacities can be customized according to customer requirements.
Application areas
Packaging industry: used for packaging of various items, such as building materials, metals, paper products, etc.
Logistics industry: used for fixing and bundling during cargo transportation.
Other industries: such as home appliances, food, chemicals, etc.
FAQ:
Q: What is the voltage of the PET plastic steel belt equipment?
A: 380V/50HZ, three-phase (customization supported)
Q: What is the extrusion capacity of the PET plastic steel belt equipment?
A: Different models have different extrusion capacities, ranging from 150-600KG/H
Q: Where does the PET plastic steel belt equipment come from?
A:shenzhen, China.
Q: What are the certifications for PET plastic steel belt equipment?
A: ISO CEO certification.
Q: What is the minimum order quantity for PET plastic steel belt equipment?
A: 1 set
Q: What is the weight of the PET plastic steel belt equipment?
20-23T, 40GP container * 3PCS
