350kg/H Capacity Pet Strap Extrusion Line for Making Packing Cargos Pet Strap

350kg/H Capacity Pet Strap Extrusion Line for Making Packing Cargos Pet Strap
350kg/H Capacity Pet Strap Extrusion Line for Making Packing Cargos Pet Strap
350kg/H Capacity Pet Strap Extrusion Line for Making Packing Cargos Pet Strap 350kg/H Capacity Pet Strap Extrusion Line for Making Packing Cargos Pet Strap 350kg/H Capacity Pet Strap Extrusion Line for Making Packing Cargos Pet Strap 350kg/H Capacity Pet Strap Extrusion Line for Making Packing Cargos Pet Strap 350kg/H Capacity Pet Strap Extrusion Line for Making Packing Cargos Pet Strap

Large Image :  350kg/H Capacity Pet Strap Extrusion Line for Making Packing Cargos Pet Strap

Product Details:
Place of Origin: CHINA
Brand Name: PET plastic steel belt production equipment
Certification: IS CEO
Model Number: JTPET-100
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: plastic film
Delivery Time: 30-40days
Payment Terms: L/C, T/T

350kg/H Capacity Pet Strap Extrusion Line for Making Packing Cargos Pet Strap

Description
Final Product: PET Packing Strap Belt Voltage: 380V/50HZ (customized )
Power: 45KW Product Name: PET Plastic Steel Belt Production Equipment
Color: REQUIREMEN BY CUSTONMER Capacity: 300-350KG/H
Strap Numer: 2-8 Strap Warranty: 1 Year
Highlight:

Packing Cargos Pet Strap Extrusion Line

,

Making Pet Strap Extrusion Line

,

350kg/H Capacity Pet Strap Extrusion Line

350kg/H Capacity Pet Strap Extrusion Line for Making Packing Cargos Pet Strap





Final products: PET packing bands, PET belt, PET strapping

PET packaging strap, also known as plastic steel tape, is a new type of binding tape that replaces steel tape. It is widely used in industries such as cotton spinning, chemical fiber, metallurgy, casting, can making, refractory materials, ceramics, brick making, glass, paper making, furiture, tobacco, wood, electronics, etc.



Technical parameter of PET belt 3output production line



Screw model 100
Number of strap 3straps
Width 9-32mm
Thickness 0.3-1.2mm
Screen changer Automatic/Manual
Control system PLC control(Chinese and English)
Production capacity 300-350kg/H
Reducer Brand GUOMAO
Motor Brand Seimens
Equipment voltage Three-phase 380v /50Hz
Tensile section Two-stage stretching

350kg/H Capacity Pet Strap Extrusion Line for Making Packing Cargos Pet Strap 0

Advantages of PET strap production line

1. process 100% recycled/PET bottle flakes.
2. even plasticization and stable extrusio with PLC automatic control for the whole line.
3. as per different requirements, changing a coating materials for making strao has better and special function.
For example, the strap for packing cotton can be from enhancing the breaking strength and joint strength when welding strap.
4. automatic filter changer with 7 filters, Filter area up to 2.5m2
5. Production line just need 2-3 workers ,suit to 24 hours moving per day.



Our service

We not only provide machines but also offer technical support and market evaluate.

We will provide all the machines for the complete production line according to customer's requirements.

We will provide complete service for factory layout and other information to help customer to build the factory.

We will provide good service for machine installation and training, until the customers can run the machines and make stably production.

Except for the one year warranty, we will provide after-sales service for all the time.

For long-term cooperation, we always provide good quality, good price and offer good service to customers.



350kg/H Capacity Pet Strap Extrusion Line for Making Packing Cargos Pet Strap 1
