Customized Color PET Belt Making Machine With Double Station Winder

Large Image : Customized Color PET Belt Making Machine With Double Station Winder

Product Details:

Place of Origin:	CHINA
Brand Name:	JIATUO CHINA
Certification:	CE SGS ISO
Model Number:	JTPET-90

Payment & Shipping Terms:

Minimum Order Quantity:	1 SET
Price:	Negotiable
Packaging Details:	plastic film
Delivery Time:	30-40 Days
Payment Terms:	L/C, T/T
Supply Ability:	10000sets

Contact Now

Customized Color PET Belt Making Machine With Double Station Winder

Description

Product Name:	PET Strap Extrusion Line	Material:	PET Bottle Flakes Material/PET Recycle Material
Power Supply:	380V/50Hz/220V/60HZ Three-phase	Automation:	PLC Computer Touch Screen
Oil Removal And Dust Removal Filter:	1set	Main Motor:	37KW(Siemens)
Neat Winding:	YES	Pre Drying Tower:	5000L
Production Capacity:	220-250kg/H	Width:	9-32mm
Thickness:	0.4-1.2mm	Line Speed:	>260m/min
Highlight:	pet belt making machines , Customized Color PET Belt Making Machine , Double Station Winder Belt Making Machine

Customized Color PET Belt Making Machine With Double Station Winder

Technical parameters of PET belt 2output production line

Screw model	90 (Single screw or double screw)
Number of strap	2 straps
Width	9-32mm
Thickness	0.3-1.2mm
Screen changer	Automatic/Manual
Control system	PLC control(Chinese and English)
Production capacity	220-250kg/H
Reducer Brand	GUOMAO
Motor Brand	Gugao
Pull of finial product	150kg-900kg
Line speed	More than 160m/min
Material	PET crushed material/bottle flake material

The features of PET packing belt production line

Diversity of raw materials: The raw materials used in this production line include PE, PP, PET, etc. these raw materials have good plasticity and processability, suitable for large-scale production.

Environmental protection: The PET polyester strapping belt produced by PET packing belt production line is a kind of recyclable environmental protection material, has good weather resistance, is stable in the temperature range of -50ºC to 100ºC, is suitable for various environmental conditions.

Efficient production: we have 2/3/4/6/8 strips at the same time, available for different production needs of customers to make a choice, and the production capacity is also very high, the output of 2 strips per hour can reach 220-250kg/H.

Process flow of PET belt production line

1. feeding to → 2.mixing raw materials→ 3. ingredients are vacuum dehumidification prebake→ 4. Vacuum dehumidification of raw materials→ 5. raw materials melting extrusion→ 6. material embryo expression(with embryo) cooling molding → 7.preheat the oven→ 8. firstly stretching → 9. secondly streching → 10. embossing → 11. tempering oven→ 12. cooling → 13.winding to finished product.

Customized Color PET Belt Making Machine With Double Station Winder 1
