PET Strap Extrusion Line with 37KW Siemens Main Motor and 5000L Pre-Drying Tower

PET Strap Extrusion Line with 37KW Siemens Main Motor and 5000L Pre-Drying Tower
PET Strap Extrusion Line with 37KW Siemens Main Motor and 5000L Pre-Drying Tower PET Strap Extrusion Line with 37KW Siemens Main Motor and 5000L Pre-Drying Tower PET Strap Extrusion Line with 37KW Siemens Main Motor and 5000L Pre-Drying Tower PET Strap Extrusion Line with 37KW Siemens Main Motor and 5000L Pre-Drying Tower PET Strap Extrusion Line with 37KW Siemens Main Motor and 5000L Pre-Drying Tower

Large Image :  PET Strap Extrusion Line with 37KW Siemens Main Motor and 5000L Pre-Drying Tower

Product Details:
Place of Origin: CHINA
Brand Name: JIATUO CHINA
Certification: CE SGS ISO
Model Number: JTPET-90
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: plastic film
Delivery Time: 30-40 Days
Payment Terms: L/C, T/T
Supply Ability: 10000sets

PET Strap Extrusion Line with 37KW Siemens Main Motor and 5000L Pre-Drying Tower

Description
Product Name: PET Strap Extrusion Line Material: PET Bottle Flakes Material/PET Recycle Material
Power Supply: 380V/50Hz/220V/60HZ Three-phase Automation: PLC Computer Touch Screen
Oil Removal And Dust Removal Filter: 1set Main Motor: 37KW(Siemens)
Neat Winding: YES Pre Drying Tower: 5000L
Production Capacity: 220-250kg/H
Highlight:

37KW PET Strap Extrusion Line

,

5000L Tower pet strap production line

,

Siemens Motor PET Strap Extrusion Line

PET Strap Extrusion Line with 37KW Siemens Main Motor and 5000L Pre-Drying Tower

Product Description of PET belt production line:

One of the key features of this PET Strap Extrusion Line is its power supply, which is 380V/50Hz/220V/60HZ Three-phase. This makes it suitable for various country as you need, ensuring that you can produce PET straps wherever you are. Additionally, the screw material used in this machine is 38CrMoALA, which is known for its toughness and durability. This ensures that the machine can handle a wide range of PET materials with ease, without wearing out quickly.

The PET Strap Extrusion Line has an extrusion capacity of 400-450KG/H, which makes it suitable for high-volume production. It can produce up to four tapes at a time, which means that you can produce more PET straps in a shorter amount of time. This makes it a highly efficient machine that can help you meet your production targets easily.

Technical parameters of PET belt 2output production line

Screw model 90 (Single screw or double screw)
Number of strap 2 straps
Width 9-32mm
Thickness 0.3-1.2mm
Screen changer Automatic/Manual
Control system PLC control(Chinese and English)
Production capacity 220-250kg/H
Reducer Brand GUOMAO
Motor Brand Siemens
Pull of finial product 150kg-900kg
Line speed More than 160m/min
Material PET crushed material/bottle flake material

PET Strap Extrusion Line with 37KW Siemens Main Motor and 5000L Pre-Drying Tower 0



The features of PET packing belt production line

Diversity of raw materials: The raw materials used in this production line include PE, PP, PET, etc. these raw materials have good plasticity and processability, suitable for large-scale production.

Environmental protection: The PET polyester strapping belt produced by PET packing belt production line is a kind of recyclable environmental protection material, has good weather resistance, is stable in the temperature range of -50ºC to 100ºC, is suitable for various environmental conditions.

Efficient production: we have 2/3/4/6/8 strips at the same time, available for different production needs of customers to make a choice, and the production capacity is also very high, the output of 2 strips per hour can reach 220-250kg/H.



Applications of PET belt production line

The JTPET PET Strap Extrusion Line is available with manual or automatic winder options, making it suitable for use in different scenarios. The manual winder option is ideal for small-scale production, while the automatic winder option is ideal for large-scale production. This PET Strap Extrusion Machinery is easy to operate and maintain, making it ideal for both experienced and inexperienced operators.



PET Strap Extrusion Line with 37KW Siemens Main Motor and 5000L Pre-Drying Tower 1

FAQ:

What is the brand name of the PET Strap Extrusion Line?

JIATUO CHINA.

2.

What is the model number of the PET Strap Extrusion Line?

JTPET.

3.

Where is the PET Strap Extrusion Line manufactured?

It is made in CHINA.

4.

What certifications does the PET Strap Extrusion Line have?

It is CE, SGS, and ISO certified.

5.

What is the minimum order quantity for the PET Strap Extrusion Line?

The minimum order quantity is 1 SET.

6.

Is the price of the PET Strap Extrusion Line negotiable?

Yes, the price is negotiable.
