Customized 9-25mm PET plastic steel strap production line PET strapping equipment pet strapping equipment with 100-600KG/KG extrusion output
Product Description of PET Strap Making Machine:
►PET Strap Making Machine is an automatic and efficient machine which is controlled by PLC control system. It is designed to produce high quality PET strap with total power of 250KW (120-120KW for operation) and speed of 200-260m/min. This machine is capable of producing PET straps for brickyard, metal, steel, aluminum and brewery. The color of the strap can be customized according to customer's requirements and the neat winding is guaranteed. This machine is also provided with a one year warranty.
►The PET packaging belt production line equipment produced by the company fully meets the environmental requirements. Plastic steel belt can be made of waste mineral water, Sprite, cola and other bottles as raw materials. The equipment is equipped with computer control system control, which is used for real-time memory control of melt temperature, pressure, extrusion speed, torque, traction, etc., to ensure the same product quality every time. The equipment is equipped with two sets of styling system, one stretching styling, two extension styling, etc. The equipment is composed of: mixing part, feeding part, drying part, dehumidification part, host part, cooling part, extension part, styling part, small traction part, large traction part, emboaching part, winding machine and so on.
►Strong temperature resistance: melting point is 260 degrees, 120 degrees below the use of deformation. · Good flexibility: no sharp edge of steel belt, safe operation, neither hurt hands nor damage to the bound object. · Beautiful without rust: no steel belt rust pollution to the bundled object, bright color can be seen. · Good economic benefits: the length of 1 ton of plastic steel belt is equivalent to 6 tons of steel belt, and the unit price per meter is lower than that of steel belt, which can reduce costs for you.
PET plastic steel belt production line features:
Extrusion process-----PET belt making machine uses a special screw for extruder, which is evenly extruded by heating and melting.
Cooling and solidification----The extruded PET belt embryo is then cooled and solidified using a cooling water tank or other refrigerator to ensure that the material maintains its shape and characteristics.
Stretching and orientation----PET belt making machines usually include stretching and orientation parts to improve the tensile strength, flexibility and overall performance of the PET belt. This process aligns the molecules in the PET material to enhance its mechanical properties.
Technical Parameters of PET Strap Making Machine:
| Product Name | PET Plastic Steel Belt Production Equipment |
|---|
Model | JTPET-100 |
|---|
Number of tapes | 4 |
|---|
| Power | 45KW(Siemens) |
|---|
Host inverter | 45KW (INVT) |
|---|
| Winding method | Manual/automatic |
|---|
| Automatic rewinding | YES |
|---|
Strap Width | 5-18mm |
|---|
| Strap Thickness | 0.6-1.2mm |
|---|
| Humanized operation | YES |
|---|
| Key Selling Points | PLC touch screen control system |
|---|
Raw material | PP polypropylene new material/recycled material |
|---|
| Automatic winding | YES |
|---|
Paper core diameter | Ø400*150mm |
|---|
| Service guaranteed | YES |
|---|
Company advantages:
The equipment is equipped with a PLC human-machine interface, which is easy to operate and debug. The equipment has an exclusive parameter memory system, which can store data for each specification after production, and can directly adjust the parameters for the next production.
The embossing wheel is processed by equipment imported from Germany, which is durable
The equipment is equipped with a correction device, and the winding is neat and knife-cut.
Services:
Our PET plastic steel belt equipment provides comprehensive technical support and services. We have an experienced technical team that can quickly provide a variety of services, including:
Pre-sales:
1. Layout of PET plastic steel belt equipment.
2. Analysis of finished product manufacturing costs of PET plastic steel belt equipment.
3. Analysis of raw materials used in PET plastic steel belt equipment.
After-sales service:
1. Waterway diagram, circuit diagram, pipeline connection drawings, etc. of PET plastic steel belt equipment.
2. Installation, commissioning and training of PET plastic steel belt equipment.
3. Maintenance service of PET plastic steel belt equipment.
4. Regular maintenance and repair
5. Fault diagnosis
6. Software update and upgrade
7. Spare parts and accessories
8. Training and technical consultation
FQA:
Q: What is the voltage of the PET plastic steel belt equipment?
A: 380V/50HZ, three-phase (customization supported)
Q: What is the extrusion capacity of the PET plastic steel belt equipment?
A: Different models have different extrusion capacities, with capacities ranging from 150-600KG/H
Q: What is the producible width of the PET plastic steel belt equipment?
A: 9-32mm
Q: Can the PET plastic steel belt equipment be customized?
A: Customization supported
Q: Where does the PET plastic steel belt equipment come from?
A: China.
Q: What are the certifications for the PET plastic steel belt equipment?
A: ISO CEO certification.
Q: What is the minimum order quantity for the PET plastic steel belt equipment?
A: 1 set
Q: What is the weight of the PET plastic steel belt equipment?
20T, 40GP container * 3PCS
