Automatic winding high speed PLC control PP strapping tape manufacturing equipment

Certification
China SHENZHEN JIATUO PLASTIC MACHINERY CO.,LTD certification
China SHENZHEN JIATUO PLASTIC MACHINERY CO.,LTD certification
Customer Reviews
Well received the PET strap making machine today, it's easy for installation and operation.

—— Ahmed from Sudan

Since using JIATUO strapping line, our production efficiency has increased dramatically and the equipment is running very stably!

—— Avinash from India

Excellent cooperation with Jiatuo Machinery, and thanks for Zoey's fast service. I am going to buy another one PP making machine!!!

—— Mustafa Koçak from Turkey

High production capability and low energy consumption, which can help me to make lots of money!!

—— Kashan from Pakistan

This is the second PP machine I ordered, the output is very high, the energy consumption is low, which greatly saves my production cost, thank you very much for Arey's patient guidance and service!

—— Hasseb from Columbia

JIATUO's technical team is very professional, door to door installation of our machine, a few days is exactly stable operation, thank you very much!

—— Farzed from Turkey

I'm Online Chat Now

Automatic winding high speed PLC control PP strapping tape manufacturing equipment

Automatic winding high speed PLC control PP strapping tape manufacturing equipment
Automatic winding high speed PLC control PP strapping tape manufacturing equipment
Automatic winding high speed PLC control PP strapping tape manufacturing equipment Automatic winding high speed PLC control PP strapping tape manufacturing equipment Automatic winding high speed PLC control PP strapping tape manufacturing equipment Automatic winding high speed PLC control PP strapping tape manufacturing equipment Automatic winding high speed PLC control PP strapping tape manufacturing equipment

Large Image :  Automatic winding high speed PLC control PP strapping tape manufacturing equipment

Product Details:
Place of Origin: CHINA
Brand Name: JIATUO CHINA
Certification: IS CEO
Model Number: JTPP-110
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: plastic film
Delivery Time: 30-40days

Automatic winding high speed PLC control PP strapping tape manufacturing equipment

Description
Equipment Layout Diagram: Customized Material: PP Polypropylene New Material/recycled Material
Production Capacity: 200-300kg/h Beautiful And Generous: YES
Strong And Durable: YES Speed: Adjustable
Screw: 110*3300mm Service Guaranteed: YES
Winding Method: Manual/automatic Total Power: 100KW(Power For Operation:50-55KW)
Overall Dimensions: L36*W2*H4(M) Paper Core Diameter: 200*180mm

Product Description of PP strapping tape manufacturing equipment:

1.The production of plastic raw materials can be made of recycled materials or mixed new materials to produce packing belts,, and calcium carbonate can also be appropriately added according to customer conditions to reduce production costs, increase product profits, and break through market competitiveness.

2.The various specifications and other extreme strapping straps produced can be applied to various automatic unmanned str rapping machines at home and abroad.

3. High output, finished product line speed can reach 260m/min.

4.High-precision and high-quality screw, using well-known brand, unique parameter design, has the advantages of large extr rusion, good plasticization, high hardness, and wear resistance.

5.The cutting of foreign-quality CNC machine tools and high-precision die parts make the product forming quality stable and the thickness error range is less than the national acceptance standard for packing straps.

6. Unique five-screw traction system, stable traction, stable equipment operation, reduced failure rate, and lower maintenanc ce costs by more than 80%.

7.The unique cooling cycle system and multiple sets of shaped guide rails make the packing belt cooler and shrink better and d more accurate in size. The internal reciprocating winding method makes full use of heat energy and efficiently reduces power loss.'

8.High-strength alloy steel wheels, shafts, gears, etc., processed by carburizing, quenching, gear grinding, etc., are wear-res sistant, durable, and effectively reduce the failure rate of equipment. High-precision embossing wheel, clear embossing, adjustable pressure, make the packing belt more beautiful.

9.Constant force winding system, uniquely designed deviation correction device, neat winding, smooth and beautiful layer.

10.Equipped with a non-stop automatic screen changer, the screen change does not need to be stopped, and the benefit is ma aximized. The equipment adopts intelligent control 11.system to operate, which is easy to understand, beautiful, durable and long life.

Automatic winding high speed PLC control PP strapping tape manufacturing equipment 0



Features of PP strapping tape manufacturing equipment:

  • Product Name: PP Strap Band Extrusion Line
  • Simple Operation: YES
  • First-class Technology: YES
  • Speed: ≥260m/min
  • Switches: Schneider
  • Extruder Power: 37KW
  • Paper core diameter:¢200*180mm
  • Width:5-18mm
  • Thickness 0.4-1.2mm
  • Gram weight:1g/m(Negotiable)


Technical Parameters of PP strapping tape manufacturing equipment:

PropertyValue
MaterialPP Polypropylene New Material/Recycled Material

Width

5-18mm

Thickness

0.4-1.2mm

Gram weight

Negotiable

Screw

110*3300mm

Motor power

37kw (Siemens)

Host inverter

37kw (INVT)

Material barrel

150KG

Feeding machine

2.7 M   1set

Double station winder

4sets
Strong and DurableYes

Replace the filter without cutting off the machine power supply

YES
Winding MethodManual/Automatic
Video Outgoing-InspectionYes
SpeedAdjustable
SwitchesSchneider
30 Years Old BrandYes
Overall DimensionsL36*W2.0*H4.0M
Neat WindingYes
Equipment VoltageThree-Phase 380V /50Hz (Customized)

Total power

100KW(Power for operation:50-55KW)


Applications of PP strapping tape manufacturing equipment:

►JIATUO CHINA's PP Strapping Band Extrusion Line (Model Number: JTPP-110) is a reliable and cost-effective solution for businesses that require a high quality, reliable strapping band extrusion line. It has been certified by IS CEO and has a minimum order quantity of 1 SET with a negotiable price. The packaging details include plastic film and a delivery time of 30-40days.
►The PP Strapping Band Extrusion Line is designed using PP polypropylene new material or recycled material, with a winding method of manual or automatic. It is also designed with 38CrMoALA screw material and the colors can be customized. It is a highly efficient production equipment for PP packing belts.
►The PP Strapping Band Extrusion Line from JIATUO CHINA is designed with superior quality materials and craftsmanship to ensure the highest quality product. It is reliable, efficient and cost-effective, making it a great choice for businesses that need a strapping band extrusion line.
►Jiatuo Machinery introduces German technology and is committed to providing customers with a complete and comprehensive one-stop solution for the production of plastic strapping,providing timely, professional and effective sales services; it has been successfully promoted to Southeast Asia, Europe, Vietnam and other countries and regions., And occupies a great advantage in the market, and achieve win-win and development goals with customers.
Automatic winding high speed PLC control PP strapping tape manufacturing equipment 1


Customization of PP strapping tape manufacturing equipment:

PP Strap Band Extrusion Line
Brand Name: JIATUO CHINA
Model Number: JTPP-110
Place of Origin: CHINA
Certification: IS CEO
Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: plastic film
Delivery Time: 30-40days
Screw: 110*3300mm
Cold and high temperature resistance: YES
Strong and durable: YES
30 years old brand: YES
Strap Thickness: 0.4-1.2mm
Keywords: PP Strapping Band Extrusion Line, PP Band Extrusion Production Line, PP Band Extrusion Line,PP Packaging tape manufacturing equipment


Support and Services of PP strapping tape manufacturing equipment:

We provide technical support and services for our PP Strap Band Extrusion Line. Our technical support team is available to answer any questions you may have about the product. We also provide on-site installation and training services. Our team of experts can help you set up the machine and make sure it is running optimally. We also offer maintenance and repair services. We can help you troubleshoot any issues you may have and get your machine up and running again in no time.
Automatic winding high speed PLC control PP strapping tape manufacturing equipment 2




Packing and Shipping of PP strapping tape manufacturing equipment:

The PP Strap Band Extrusion Line is shipped in wooden cases that are securely fastened and sealed. The cases are filled with foam to protect the product from any damage during transportation. The cases are labeled with the company name and logo, as well as the product name and serial number. All cases are shipped via reliable courier services or freight services depending on the size and weight of the product.
