Single Screw 4 Cavity PP Strap Extrusion Line PP Strap Making Machine
Quick Detail Of PP Strap Making Machine
Name: PP 1 to 4 strapping production line
Model number: JTPP-110
Applicable raw materials: New PP particles, PP recycled materials, PP crushed materials
Number of screws: 1 Screw
Number of extruded belts: 4
Width range: 5-19mm
Thickness range: 0.4-1.2mm
Production capacity: 200kg/h
Installation size: L38*W2.0*H4.0(m)
Configuration Of PP Strapping Production Line
| NO. |
Name |
QTY |
| 1 |
Color Mixer |
1 set |
| 2 |
Vacuum feeder or screw loader feeder
(100% raw material use vacuum feeder machine;recycled material use screw loader feeder machine) customer choose one of it. |
1 set |
| 3 |
Hopper dryer |
1 set |
| 4 |
SJ single screw extruder |
1 set |
| 5 |
High speed Screen exchanger device |
1 set |
| 6 |
Molud |
1 set |
| 7 |
Water cooling tank |
1 set |
| 8 |
The first traction machine- 5 rollers |
1 set |
| 9 |
The first Stretch forming oven |
1 set |
| 10 |
The Second traction machine- 5 rollers |
1 set |
| 11 |
The second Stretch forming oven |
1 set |
| 12 |
The Third traction machine- 3 rollers |
1 set |
| 13 |
Embossing machine |
1 set |
| 14 |
The Winder machine |
1 set |
Features Of PP Strap Extrusion Line
1. Better tensile strength: the PET strap production line has the tensile strength of the steel belt, and the ductility is good, and the anti-impact performance is better. It is not easy to break, and it can ensure the safety of product transportation.
2. Small extension: Although PET strap is one kind of plastics, its extension of change is very small, its elongation is only 1/ 6 of polypropylene, it can maintain tension force, after the packing make the expansion no longer change.
3. Strong temperature resistance: the experiment proved that the melting point of PET packing belt at about 260 ℃, can be used under the environment of 120 ℃ for a long time not to distort,it has a good stability.
4. Good economic benefit: the density of PET packaging belt is 1.30 ~ 1.38 g/cm3, which is only 1/6 of the steel belt density (7.8 g/cm3), which is equivalent to the length of the 6-ton steel belt, and the price of the same unit length is relatively low.
5. Environmentally friendly: the steel belt will rust due to exposure to the air, and the rust is highly permeable to the packaging. PET packing tape is beautiful and not rusted, but avoid unnecessary worry. It can also be recycled.
6. Good flexibility and safe operation: the PET packing strip has no sharp edge with steel belt, it will not scratch the package, and it will not hurt the hand. You don’t need a special tool when you cut it, even if it’s tight, it doesn’t hurt when you cut it.
7.High quality packaging ideal products: PET packaging with all kinds of bright colors, shiny, high quality, the most ideal packaging products of high-end packaging
FAQ About PP Belt Strapping Production Line
Q1:Are you a trading company or a factory?
A1:We are a factory,can give u best service.
Q2:When can I get my machine after I paid?
A2:We will deliver the machines on time as the date we agreed both side.
Q3:How can I install my machine when it arrives?
A3:We will send our engineer to your side as soon as you get all your machines ready , for testing and teaching your technicians how to run the machines.
Q4:What's your guarantee or the warranty of the quality if we buy your machines?
A4:We offer you high quality machines with 1 years guarantee . we will give u spare part free in 1 years.
