Tensile Strength 850kgs Plastic PET Strap Making Machine Production Line
Tensile Strength>850kgs Plastic PET Strapping Band Production Line Bandwidth 9-32mm
Description of PET strap band production machine:
This production line is used to produce the plastic steel packing strap, adopt the PLC control the whole line do the automatic production, it use the melting pump and pressure sensor ensure the production stable and strap quality control the raw material you can use is 100% recycled PET flakes from the waste PET bottles, virgin material or mixed with each other.
Application for plastic steel strapping:
As a new type of strapping product with strong tensile force and corrosion resistance, PET strapping belt is gradually replacing traditional stainless steel strapping products with overwhelming advantages in performance and price. Therefore, the potential of PET strapping production line as a small and medium-sized investment is huge.It is widely used in steel, aluminum, chemical fiber, cotton spinning, tobacco, paper, metal can making and other industries.
Parameters of PET Belt Strapping Band Production Line:
| Model |
PET-2 |
PET-3 |
PET-4 |
PET-6 |
| Production materials |
Bottle flakes / broken material |
| Number of lines |
2 |
3 |
4 |
6 |
| Outgoing bandwidth(mm) |
9-32 |
9-32 |
9-32 |
9-32 |
| Outlet thickness(mm) |
0.6-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
| Control sytem |
PLC control |
| Screw model |
90 |
100 |
125 |
150 |
| Reducer model |
200 |
250 |
280 |
315 |
| Horizontal mixer |
2500L |
2500L |
5000L |
5000L |
| Drying tower |
3000L |
4000L |
5000L |
6000L |
| Host barrel |
3000L |
4000L |
5000L |
6000L |
| Production capacity/ 24H |
4.8T |
8T |
10T |
15T |
PET packaging belt production line process flow:
① feeding→② mixing raw materials→③ raw material pre-drying→④ vacuum dehumidification of raw materials→⑤ raw materials melting extrusion→⑥ material embryo expression(with embryo) cooling molding→⑦oven preheating→⑧first stretching→⑨second stretching→⑩embossing→⑪ oven tempering to set the shape→⑫ cooling → ⑬winding(finished product)
Features of PET Strap production machine:
-
PET strapping machine,using the 100% recycled pet bottle flakes as raw materials by making them melt directly,which reduces the course of raw material-making.
-
Can produce 9-32mm strap, 2/3/4/6 lines
-
High tension force according to your needs
-
Low energy consumption, high production capability.
-
Easy to operate ,save manpower
PET strapping finished products:
