PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold

PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold
PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold
PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold

Large Image :  PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold

Product Details:
Place of Origin: SHENZHEN CHINA
Brand Name: JIATUO
Certification: CE ISO SGS
Model Number: JTPET-90
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: USD 140,000-USD 280,000 PER SET
Packaging Details: Suitable for Sea Shipment
Delivery Time: 30 days
Supply Ability: 60 sets/Year

PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold

Description
Control System: PLC Cooling System: Air Cooling
Dimension: 4500*1200*1800mm Heating System: Electrical Heating
Max. Output: 80-120kg/h Max. Speed: 50m/min
Operation Mode: Automatic Power: 380V/50HZ
Product Name: PET Strap Making Machine Strap Material: 100% Recycled Bottle Flakes
Strap Thickness: 0.4-1.2mm Strap Width: 9-19mm
Tension Control: Pneumatic Warranty: 1 Year
Weight: 2500kg Assembly Structure: Integral Type Extruder
Screw Type: Single-screw

PET Plastic Packing Belt Double Output Making Machine

PET Packing Strap Production Line



Process Flow of PET Packing Strap Production Line:

PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold 0

①Material→②Stirring raw material→③Pre crystallization drying→④vacuum dehumidification→⑤Extruding→⑥cooling and forming →⑦ oven preheating →⑧ primary stretching →⑨secondary stretching →⑩ embossing → ⑪shaping→⑫ cooling→ ⑬winding



Machine Description:


PET Strap Making Machine is using pet bottle flakes, to produce various specifications of pet strap.



PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold 1



PET Packing Strap Production Line Details:



No. Name Qty
1 Dehumidifying and Crystallizing Unit 1 set
2 Oil and dust filter 1 set
3 Single Screw Extruder 1 set
4 Single Cylinder Filter 1 set
5 Melt Pump 1 set
6 Die Head 1 set
7 Cooling Water Tank 1 set
8 Stretching Oven 1 set
9 Five Roller Gearbox 3 sets
10 PLC Control System 1 set
11 First and Second Stretching Rollers 1 set
12 Shaping Oven 1 set
13 Five-roller Haul-off Device 1 set
14 Fourth Haul-off Rollers 1 set
15 Winder 2 sets



1. Extruder

PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold 2

---Specially designed screw and barrel for different materials


----Optional material drying and loading system for different materials

2. Material Filter, Melt Pump ,Extrusion Mold and Cooling Tank
PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold 3

--- Candle type filter, bigger filtering area, longer working time, no need change filters shortly.

----Close--loop control system from extruder to melt pump, by which extrusion can be automatically controlled by melt pump.
----Melt pump ensures stable extrusion

---304 stainless steel water cooling tank



3. Extrusion Mold

PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold 4PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold 5

--- Good quality and special treatment

----Produce different sizes of strpas.
----1-6 straps extruding, according to customer request and straps size.



4. Hual-off Rollers

PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold 6

----Gear transmission
----Chromed rollers

5. Shaping Oven

PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold 7

---Forced air blowing system
---Inverter control
---Good heat-preservation
6. Winder
PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold 8

PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold 9

---PLC winding machine
---Winding weight as customer needs



Parameters of PET 1 to 2 production machine:



Item JTPET-90
Screw design Single screw
Straps Qty. 2 straps
Output/Day 5.5-6T/24 hours
Screw Dia. 90mm
Winder Qty. 2 sets
Material used 100% Recycled Bottle Flakes/Virgin Material/mixed with
Running power 110-120kw
Installed power 200kw
Strap specifications Width 9-32mm thickness 0.6-1.2mm
Workshop area L (55m) ×W (2m) ×H (7m)
Electric components Schneider
Materials PET raw material or 100% PET bottle flakes recycled

PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold 10

Final Products of PET Strap Band/Belt Extrusion Line/ PET Strap Band/Belt Extrusion Machine

PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold 11

PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold 12

Features of  PET Strap Making Machine


1.Screw with compression ratio especially for PP/PET, gradually changing diameter and deeper thread groove at the melting part.

2. Gearbox with hardened gears; Die can be precisely adjusted to ensure stable production and smooth surface of straps.

3.Precise dosing and raw material mixing.
4.Preheat and dry circulating automatically.
5.Even plasticization, stable extrusion and accurate temperature control.
6.Big hauling force stretching device and isolated heating oven.
7.Large capacity stainless steel water tank, automatic liquid level control.



PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold 13



Advantages for PET Strap Making Machine:



  • Special twin screw extrusion technology and single screw extrusion technology can be choosing as per customer needs.

  • Process 100% recycled PP/PET bottle flakes or pellets.

  • Even plasticization and stable extrusion with PLC automatic control for the full line.

  • Melt pump ensure continuously stable producing.

  • 1-6 straps extruding, according to customer request and straps size.

  • Produce monofilament by changing some parts.
  • Servo or torque motor for winding machine are available.



Machine Products Description:


Applications: widely used in steel, chemical industry, aluminum, paper making, brick kiln, tobacco, electronics, textile and timber industries.



Screw dia 90mm PET Plastic Packing Belt Making Machine Two Way Cylinder 1

PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold 15

PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold 16

Package and Delivery:



PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold 17PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold 18

PET Packing Belt/Tape Extruding Machinery for Packing Fully Automatic Packing Machine Extrusion Mold 19



Service and Support:



1. Pre-sales Service:



* Showing the production video

* Supply the FAQ questions

* Project evaluation

* Marketing trends analysis

* Showing our customer's factory in local

* Visit our company



2. During-manufacturing



* Provide layout and engineering condition

* Inform the schedule of production

* Test machine before shipment

* Sending photos before loading



3. After-sales Service



* Overseas installation

* Training the workers

* Build customer database to tracking machine conditions

* Space parts supply in soonest time

* Visit customer and solve the problems they have

* Teach the products care and maintenance skills



FAQ:


Q: Is your company factory or trade company?
A: we are factory, we are engaged in this business for 20 years, we also have our own PET straps  factory.



Q: What is the procedure when you buy our machine?
A:Confirm the technology and machine configure -----confirm price----sign contract and make PI---send down payment - start to make machine---inform you before machine finish-you come our factory to check the machine---you accept the machine ----finish payment-exporting---send our technicians to your factory install the machine---answer your question all the using time and supply spare parts with cost only.


Q: Can you guarantee your quality?
A: Of course. We are the manufacture factory. More importantly, we put a high value on our reputation. Best quality is our principle all the time. You can be assured on our production completely.


Q: What is the payment term?
A: The best way for both of us is 30% T/T deposit and 70% T/T balance payment before shipping, since we will test the machine before shipping. Of course, you can choose the way that more convenient (Payment terms: T/T, L/C, Western Union etc.)
