Memory System PP Strap Band Extrusion Line For Automatic Packing High Precision 400kgs/H

Memory System PP Strap Band Extrusion Line For Automatic Packing High Precision 400kgs/H
Memory System PP Strap Band Extrusion Line For Automatic Packing High Precision 400kgs/H Memory System PP Strap Band Extrusion Line For Automatic Packing High Precision 400kgs/H Memory System PP Strap Band Extrusion Line For Automatic Packing High Precision 400kgs/H Memory System PP Strap Band Extrusion Line For Automatic Packing High Precision 400kgs/H Memory System PP Strap Band Extrusion Line For Automatic Packing High Precision 400kgs/H Memory System PP Strap Band Extrusion Line For Automatic Packing High Precision 400kgs/H

Large Image :  Memory System PP Strap Band Extrusion Line For Automatic Packing High Precision 400kgs/H

Product Details:
Place of Origin: CHINA
Brand Name: JIATUO CHINA
Certification: ISO/ CE
Model Number: JTPP-125
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: Plastic film
Delivery Time: 50-60DAYS To be negotiated
Payment Terms: L/C, T/T

Memory System PP Strap Band Extrusion Line For Automatic Packing High Precision 400kgs/H

Description
Plastic Processed: PP Screw Diameter (mm): 125mm
Production Capacity: 360-400kgs/H Warranty: 1 Years
Number Of Extruded Strap: 6 Application Scope: Some Light Cargoes (>240kgs)
Screen Changer: Automatic/handle Thickness Range: 0.4-1.2mm
Width Range: 9-19mm Applicable Raw Materials: 100% Recycled Material
Melting Point: 260 Temperature Keywords: Strap Making Machine
Key Selling Points: High Productivity Winding: Fully Automatic/ Semi Automatic
Inverter: IVNT Motor: Siemens
Winder: 6 Set Worn Parts: Provide Some For Free
Extruder: Single Screw Extruder Screen Changer: Automatic/ Manual
Highlight:

High Precision PP Strap Band Extrusion Line

,

PP Strap Band Extrusion Line 400kgs/H

Memory System PP Strap Band Extrusion Line For Automatic Packing With High Precision



Description

PP strap band production machine:
PP packaging tapes made from the raw material polypropylene modified high quality additives, effectively improve you pack the product performance, improve the flexibility and hardness, can be effective within the portal frame of full automatic packing machine. You pack after six steps: high temperature extrusion, stretching, pressing, cooling and shaping, winding packaging production technology refined but become, pack the width and thickness of high precision and uniform density; Strong adhesive force, pulling force is large, light quality, corrosion resistance, appearance beautiful, upscale. In addition, both the left and right sides of the straps have edge lines, and can effectively improve the tighten force, is the automatic packing machine and fully automatic unmanned packer's ideal material.







Compositions

PP belt production line:



1 Vacuum feeder 1 set
2 Hopper dryer 1 set
3 Feeding machine 2 set
4 ¢125 Extruding Machine 1 set
5 Automatic Screen filter changer 1 set
6 Mould(1 mould for 6 output) 1 set
7 Water cooling tank system 1 set
8 The first haul-off device 1 set
9 Stretching oven 1 set
10 The second haul-off device 1 set
11 PLC electrical control system 1 set
12 Embossing machine 1 set
13 Forming oven 1 set
14 Cooling system 1 set
15 The third haul-off device 1 set
16 Double disk winder 6 set



Memory System PP Strap Band Extrusion Line For Automatic Packing High Precision 400kgs/H 0

Features

PP strap band production machine:



1. The machine adjusts is conversion motor as power source .
2. The mechanical transmission adopts soft connection.
3. Its rotation is exact and smooth, saving power and low noise.

4.The use of the product is convenient, it can adopt common steel fastening for connection.

5.It also is suitable for various kinds of hand-operated of table packing machine and large auto packing machine of enterprises.



After sales service

1. Pre-sale service
To provide information, market research and forecasting, provide consultancy, offers a variety of convenience and market service and so on.
Pre-sale service's main purpose is to assist the clients prepare the project planning and system requirements analysis, enable our products to maximize meet customer needs, but also to maximize customer investment play the comprehensive economic benefits.


2. After-service

  • Free installation and debugging
  • Provide all kinds of product formula, technology and chemical material manufacturer information
  • According to the customer's requirements, provide technical guidance
  • Technical training for employees of customers
  • Responsible for maintenance service, door to door service if necessary.

Memory System PP Strap Band Extrusion Line For Automatic Packing High Precision 400kgs/H 1
