Product Details:
Place of Origin: Shenzhen, China
Brand Name: JIATUO
Certification: CE, ISO
Model Number: JTPP-90
Document: parameter details of PP Str...ne.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plastic film or other standard package for sea shipping
Delivery Time: 50~55 working days
Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability: 50set/month
Contact Now

High-speed strapping equipment 5-15mm single screw PP strapping production line PP packaging strap equipment PP extruder for PLC control system

Description
Product Type: PET PP Packing Strapping Band Production Line / Strap Extruder / PET Tape Extrusion Machine Raw Material: Polypropylene PP Raw Material Pellets, Recycled Pellets
Screw Design: Optional Twin Screw Type: Co-rotating Parallel Twin-screw
Driven Type: Electric Processing Type: Extruding Machine
Automation: Automatic Application: Packaging Strap
Width: 5-19mm Thickness: 0.4-1.2mm
Highlight:

0.4mm PP Strap Extruder

,

1.2mm PP Strap Extruder

,

1.2mm PET Strap Extrusion Line

High-speed strapping equipment 5-15mm single screw PP strapping production line PP packaging strap equipment PP extruder for PLC control system



Quick Detail Of PP Strap Making Machine

Name: PP 1 to 4 strapping production line

Model number: JTPP-110

Applicable raw materials: New PP particles, PP recycled materials, PP crushed materials

Number of screws: 1 Screw

Number of extruded belts: 4

Width range: 5-19mm

Thickness range: 0.4-1.2mm

Production capacity: 200-600kg/h

Installation size: L38*W2.0*H4.0(m)


Configuration Of PP Strapping Production Line

NO. Name QTY
1 Color Mixer 1 set
2 Vacuum feeder or screw loader feeder
(100% raw material use vacuum feeder machine;recycled material use screw loader feeder machine) customer choose one of it.		 1 set
3 Hopper dryer 1 set
4 SJ single screw extruder 1 set
5 High speed Screen exchanger device 1 set
6 Molud 1 set
7 Water cooling tank 1 set
8 The first traction machine- 5 rollers 1 set
9 The first Stretch forming oven 1 set
10 The Second traction machine- 5 rollers 1 set
11 The second Stretch forming oven 1 set
12 The Third traction machine- 3 rollers 1 set
13 Embossing machine 1 set
14 The Winder machine 1 set

High-speed strapping equipment 5-15mm single screw PP strapping production line PP packaging strap equipment PP extruder for PLC control system 0

High-speed strapping equipment 5-15mm single screw PP strapping production line PP packaging strap equipment PP extruder for PLC control system 1High-speed strapping equipment 5-15mm single screw PP strapping production line PP packaging strap equipment PP extruder for PLC control system 2

Features Of PP Strap Extrusion Line



Screw------The machine uses high-quality 38CrMoALA screw material, which is famous for its excellent strength and durability.

Type------Single screw/twin screw extruder can be used, and the size can be customized according to customer requirements.

Winding machine-----PP belt making machine can be equipped with semi-automatic winding machine & fully automatic winding machine

Line speed---------200-300 m/min





FAQ ABOUT PP STRAPPING BAND EXTRUSION LINE



1. For PP(polypropylene) strapping band extrusion line
* What about the output of PP strapping band extrusion line? 150kg/hr, 280kg/hr, 500kg/hr.
* What about the size of strap that the PP strap machine can make? Width: 5-19mm; Thickness: 0.4-1.0mm;
* What about the installation power of the PP strap machine? 135kw/155kw/195kw/439kw;

2. For PET(polyester) strapping band extrusion line
* What about the output of PET strapping band extrusion line? 200kg/hr, 400kg/hr, 600kg/hr, 800kg/hr.
* What about the size of strap that the PET strap machine can make? Width: 9-32mm; Thickness: 0.35-1.2mm;
* What about the installation power of the PET strap machine? 215kw/285kw/352kw/900kw;

High-speed strapping equipment 5-15mm single screw PP strapping production line PP packaging strap equipment PP extruder for PLC control system 3
