Single Screw PET Strap Making Machine 2 Output Straps Extruder Production Line

Single Screw PET Strap Making Machine 2 Output Straps Extruder Production Line
Single Screw PET Strap Making Machine 2 Output Straps Extruder Production Line Single Screw PET Strap Making Machine 2 Output Straps Extruder Production Line Single Screw PET Strap Making Machine 2 Output Straps Extruder Production Line

Large Image :  Single Screw PET Strap Making Machine 2 Output Straps Extruder Production Line

Product Details:
Place of Origin: Shenzhen, China
Brand Name: JIATUO
Certification: CE, ISO
Model Number: JTPET-90
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plastic film or other standard package for sea shipping
Delivery Time: 50~55 working days
Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability: 50 set/month

Single Screw PET Strap Making Machine 2 Output Straps Extruder Production Line

Description
Product Type: PET Strap Making Machine Raw Material: PET Flakes Or 100% Recycled Material
PET Thickness Range: 0.6-12mm PET Strap Width: 9-32mm
Capacity: 200~350kg/h Motor: Siemens
Driven Type: Electric Product Color: Green/Pink/yellow/black
Application: Packaged Material Voltage: According To Customer's Factory
After-sales Service Provided: Video Technical Support, Online Support Warranty: 1 Year
Highlight:

Single Screw PET Strap Making Machine

,

350kg/h PET Strap Making Machine

,

2 Extruder PET Strap Production Line

Single Screw Output 2straps Extruder PET Strap Making Machine Production Line


PET PACKAGING BELT EXTRUDING MACHINE DESCRIPTION

This production line can produce different with and thickness of PP PET strap according to client's requirement. This extrusion line is mainly for producing PP PET strap. The raw material can be 100% recycled material, which can reduce the produce cost and get a good profit. And the PP PET belt is the substitution of the steel strap and has lots of advantages such as good extension, high temperature resistance, easy use, etc

The PET /PP packing belt has the characteristic of high stretch-resistant,low extend rate,
impact-resistant,good flexible,easy for operate ,cheap and safe.

Now it is widely used in the steel industry, chemical fiber industry, aluminum ingots, paper, brick kiln industry, tobacco industry,electronics, textiles and wood, etc.

It is perfect substitute of steel belt,used in packing paper ,wood work ,textile,cotton,fibre and pallet.

PET Strap Production Line Machine List

NO. Item Specification
1 Power According to customer's factory voltage
2 Material PET raw material or 100% PET bottle flakes recycled
3 Capacity

PETJT90:200kg/h

PETJT100:250kg/h

PETJT125:350kg/h

4 Product size

Width:9-32mm

Thickness:0.6-12mm

6 Mid-height of extruder 7000mm
7 Installation power

PETJT90:200KW

PETJT100:250KW

PETJT125:300KW

8 Humidity <85%
9 Temperature 0-40 degree
10 Cooling tower capacity 30T/H or 50T/H
11 Installation Dimensions

PETJT90:45*2.0*7.0M

PETJT100:45*2.0*7.0M

PETJT125:60*3.0*8.0M

12 Product color Green/Black/Pink/Yellow
13 Factory dimension

35m*(3~6)m*(4~6)m

45m*(3~6)m*(4~6)m

If your factory not big enough,please contact with us,our engineer can according to your size to design

Single Screw PET Strap Making Machine 2 Output Straps Extruder Production Line 0
Advantages of PET strap

  • Use 100% Recycled PET/PP Flakes to reduce the cost.
  • Good dehumidifer drying system(Crystallization system optional ) to ensure the material equal dryer to produce high quality strapping.
  • Special design hot forming tensile tank to make good forming ,equal width,straight strap.

Features of PET packing strap production line:

1. It is a high tech enterprise which is specialized in research, manufacture and marketing plastic recycling machine, pp strap making machine, plastic strap extruder line, pp strapping band production and pet recycling line, plastic washing and recycling line.
2.Our plastic extrusion lines based on Plastic Extruders: Single Screw Extruder, Conical Twin Screw Extruder and Parallel Twin Screw Extruder.

3.Our plastic extruder machine many kinds of plastic productions like: plastic granules, plastic pellets, pp strap, strapping band, pp tape band, plastic strap and so on.
4.Plastic Extuder is widely used in Plastic industry. It is the main part of Plastic Profile Extrusion Line,Plastic Recycling Line and Plastic Granulating Line.

5.Our plastic extruder use good quality screw in plastic machinery.Our plastic machine have long-life.

Single Screw PET Strap Making Machine 2 Output Straps Extruder Production Line 1


FAQ



1. Q: How can I purchase your goods?
A: Please choose your perfect item and tell us your size, quantity and packing you want.
2. Q: How long is the lead time?
A: Normal order within 10-30 days after deposit.
3. Q: Do you offer sample?
A: Samples can be sent for your reference, but charge is required, after making formal order, the cost of samples will be cut from the total amount.
4.Q: What is the MOQ on your products?
A: Small quantity can be acceptable, depends on the stock.

Single Screw PET Strap Making Machine 2 Output Straps Extruder Production Line 2
