Join Pack Handheld Strapping Machine 780mm Mechanical Tension Control

Join Pack Handheld Strapping Machine 780mm Mechanical Tension Control
Join Pack Handheld Strapping Machine 780mm Mechanical Tension Control Join Pack Handheld Strapping Machine 780mm Mechanical Tension Control

Large Image :  Join Pack Handheld Strapping Machine 780mm Mechanical Tension Control

Product Details:
Place of Origin: Shenzhen, China
Brand Name: JOIN
Certification: CE, ISO
Model Number: ES101
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plastic film or other standard package for sea shipping
Delivery Time: 10~15working days
Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability: 100 set/month

Join Pack Handheld Strapping Machine 780mm Mechanical Tension Control

Description
Product Name: Semi Automatic Strapping Machine Cycle Time: 2.5 Sec./strap
Tension Range: 15~45kgs Strap Width: 9,12,15.5mm Adjustable
Sealing Method: Heating Element Reel Inside Diameter: 200,230,280mm Specified
Power Supply: 100/110/220/230/240V 50/60HZ, 1PH Table Height: 780mm
Power Consumption: 0.4kw Machine Dimension (L X W X H Mm): L902 X W575 X H780
Highlight:

Heating element Handheld Strapping Machine

,

780mm Handheld Strapping Machine

,

Mechanical Tension Control Handheld Strapping Machine

Join Pack Semi Automatic Strapping Machine Mechanical Tension Control

PRODUCT DESCRIPTION

Semi-automatic Strapping Machine is easy to manipulate. The strapping tension can be adjusted from 30 to 450N. In the package with the machine are all necessary accessories so you are able to get your bundling process started as soon as the package arrives.

Semi-automatic Strapping Machine can be used in all sorts of industries or warehouses and will speed up your work thus making your employees more productive. The semi-automatic machine uses the latest strapping technology and it is designed to deliver a high-grade friction weld seal.

Cycle Time 2.5 sec./strap
Tension Range 15~45kgs
Strap Width 9,12,15.5mm adjustable
Sealing Method Heating element
Reel Inside Diameter 200,230,280mm specified
Power Supply 100/110/220/230/240V 50/60HZ, 1PH
Table Height 780mm
Power Consumption 0.4kw
Machine Dimension
(L x W x H mm)
L902 x W575 x H780
Machine Weight
(50%,100%,150%,200%)
90kgs

Join Pack Handheld Strapping Machine 780mm Mechanical Tension Control 0



Features of the semi-automatic strapping machine for PET strap:









  • Hinged table top
  • Mechanical tension control
  • Motor shut off for energy saving
  • Easy operation, less maintenance
  • Reliable PCB and control components

Join Pack Handheld Strapping Machine 780mm Mechanical Tension Control 1

How to use semi-automatic strapping machine:



1. Power switch: Turn ON to start the machine, and OFF to stop the machine.

2. Power indicator light (POWER): Turn on the power switch, the light is on.

3. Length adjustment for strap feeding (TIMER): Every one scale is about 500mm.For any adjustment that is required turn it in the clockwise direction. The length of the strap will then become longer.

4. Strap tension button (TENSION): Choose the tension degree of a strap according to the size of the package.

5. Manual feeding/Reset button (FEED/HOME): Press the FEED button to help feed the straps. The longer you press, the longer the strap will be. 6. If the machine is not at the home position, press the HOME button so that the machine will return to its home position.

7. Cooling time adjustment (COOL TIME): Depending on the strap and the different tensile strength, adjust the cooling time, for better adhesion effects.

8. Safety door switch: If the top cover is opened, the machine will stop running automatically. (Please turn off the main power switch before opening top cover.

Join Pack Handheld Strapping Machine 780mm Mechanical Tension Control 2
