High-speed semi-automatic and fully automatic strapping machines PP PET strapping packaging machines
PRODUCT DESCRIPTION OF SEMI AUTOMATIC STRAPPING MACHINE
Semi-automatic Strapping Machine is easy to manipulate. The strapping tension can be adjusted from 30 to 450N. In the package with the machine are all necessary accessories so you are able to get your bundling process started as soon as the package arrives.
Semi-automatic Strapping Machine can be used in all sorts of industries or warehouses and will speed up your work thus making your employees more productive. The semi-automatic machine uses the latest strapping technology and it is designed to deliver a high-grade friction weld seal.
| Cycle Time |
2.5 sec./strap |
| Tension Range |
15~45kgs |
| Strap Width |
9,12,15.5mm adjustable |
| Sealing Method |
Heating element |
| Reel Inside Diameter |
200,230,280mm specified |
| Power Supply |
100/110/220/230/240V 50/60HZ, 1PH |
| Table Height |
780mm |
| Power Consumption |
0.4kw |
Machine Dimension
(L x W x H mm) |
L902 x W575 x H780 |
Machine Weight
(50%,100%,150%,200%) |
90kgs |
Features:
Semi-automatic strapping machines:
Specifically, the manual tasks required are:
Apply the strapping tape around the box.
Insert the front end of the tape into the machine.
After strapping is complete, the manual tasks involve removing the box.
Automatically, the machine performs the following tasks:
Tighten the strapping belt.
Fuse the ends of the tape together using hot melt.
Cut the strapping belt
How to use semi-automatic strapping machine:
1. Power switch: Turn ON to start the machine, and OFF to stop the machine.
2. Power indicator light (POWER): Turn on the power switch, the light is on.
3. Length adjustment for strap feeding (TIMER): Every one scale is about 500mm.For any adjustment that is required turn it in the clockwise direction. The length of the strap will then become longer.
4. Strap tension button (TENSION): Choose the tension degree of a strap according to the size of the package.
5. Manual feeding/Reset button (FEED/HOME): Press the FEED button to help feed the straps. The longer you press, the longer the strap will be. 6. If the machine is not at the home position, press the HOME button so that the machine will return to its home position.
7. Cooling time adjustment (COOL TIME): Depending on the strap and the different tensile strength, adjust the cooling time, for better adhesion effects.
8. Safety door switch: If the top cover is opened, the machine will stop running automatically. (Please turn off the main power switch before opening top cover.
