200kg/H Pet Strapping Band Making Machine 100% Recycled Material Extrusion

200kg/H Pet Strapping Band Making Machine 100% Recycled Material Extrusion
200kg/H Pet Strapping Band Making Machine 100% Recycled Material Extrusion
200kg/H Pet Strapping Band Making Machine 100% Recycled Material Extrusion 200kg/H Pet Strapping Band Making Machine 100% Recycled Material Extrusion 200kg/H Pet Strapping Band Making Machine 100% Recycled Material Extrusion

Large Image :  200kg/H Pet Strapping Band Making Machine 100% Recycled Material Extrusion

Product Details:
Place of Origin: Shenzhen, China
Brand Name: JIATUO
Certification: CE, ISO
Model Number: JTPET-90
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plastic film or other standard package for sea shipping
Delivery Time: 50~55 working days
Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability: 50 set/month

200kg/H Pet Strapping Band Making Machine 100% Recycled Material Extrusion

Description
Product Type: PET Strap Making Production Line Raw Material: PET Flakes Or 100% Recycled Material
PET Strap Width: 9-32mm PET Thickness Range: 0.6-12mm
Capacity: 200kg/h Driven Type: Electric
Motor: Siemens Voltage: According To Customer's Factory
Product Color: Green/Pink/yellow/black Application: Packaged Material
After-sales Service Provided: Video Technical Support, Online Support Warranty: 1 Year
Highlight:

200kg/H Pet Strapping Band Making Machine

,

100% Recycled PET Strap Extrusion Line

,

200kg/H PET Strap Extrusion Line

Recycled PET Tape Making Machine Extrusion Line Environmentally Friendly Packaging


PRODUCT DESCRIPTION

Pet packing belt one out two production line equipment:
Pet belt (commonly known as plastic steel belt) is a new type of binding belt which is currently popular in the world to replace steel belt. It is widely used in steel, aluminum, chemical fiber, cotton spinning, paper industry, wood industry, building materials, metal products and other industries.

PET Strap Production Line Machine List

NO. Item Specification
1 Power According to customer's factory voltage
2 Material PET raw material or 100% PET bottle flakes recycled
3 Capacity

PETJT90:200kg/h

PETJT100:250kg/h

PETJT125:350kg/h

4 Product size

Width:9-32mm

Thickness:0.6-12mm

6 Mid-height of extruder 7000mm
7 Installation power

PETJT90:200KW

PETJT100:250KW

PETJT125:300KW

8 Humidity <85%
9 Temperature 0-40 degree
10 Cooling tower capacity 30T/H or 50T/H
11 Installation Dimensions

PETJT90:45*2.0*7.0M

PETJT100:45*2.0*7.0M

PETJT125:60*3.0*8.0M

12 Product color Green/Black/Pink/Yellow
13 Factory dimension

35m*(3~6)m*(4~6)m

45m*(3~6)m*(4~6)m

If your factory not big enough,please contact with us,our engineer can according to your size to design

200kg/H Pet Strapping Band Making Machine 100% Recycled Material Extrusion 0

Features of PET packing strap production line:

  • 1. Better tensile strength: the PET strap production line has the tensile strength of the steel belt, and the ductility is good, and the anti-impact performance is better. It is not easy to break, and it can ensure the safety of product transportation.

  • 2. Small extension: Although PET strap is one kind of plastics, its extension of change is very small, its elongation is only 1/ 6 of polypropylene, it can maintain tension force, after the packing make the expansion no longer change.

  • 3. Strong temperature resistance: the experiment proved that the melting point of PET packing belt at about 260 ℃, can be used under the environment of 120 ℃ for a long time not to distort,it has a good stability.

  • 4. Good economic benefit: the density of PET packaging belt is 1.30 ~ 1.38 g/cm3, which is only 1/6 of the steel belt density (7.8 g/cm3), which is equivalent to the length of the 6-ton steel belt, and the price of the same unit length is relatively low.

  • 5. Environmentally friendly: the steel belt will rust due to exposure to the air, and the rust is highly permeable to the packaging. PET packing tape is beautiful and not rusted, but avoid unnecessary worry. It can also be recycled.

  • 6. Good flexibility and safe operation: the PET packing strip has no sharp edge with steel belt, it will not scratch the package, and it will not hurt the hand. You don’t need a special tool when you cut it, even if it’s tight, it doesn’t hurt when you cut it.

  • 7.High quality packaging ideal products: PET packaging with all kinds of bright colors, shiny, high quality, the most ideal packaging products of high-end packaging

200kg/H Pet Strapping Band Making Machine 100% Recycled Material Extrusion 1

200kg/H Pet Strapping Band Making Machine 100% Recycled Material Extrusion 2
