PP strapping production line 5-19mm PP strapping machine automatic servo winding machine
DESCRIPTION OF PP STRAPPING BAND MAKING MACHINE
pp strapping band making machine is a high-speed extruder that can produce PP strapping band for strapping various products.
p strapping band making machine
1. Single-screw or twin-screw extruders are available, depending on raw material availability and production requirements.
2. 100% recycled polypropylene pellets or virgin material can be used.
3. Hydraulic quick screen changer is used.
4. Melt metering pump ensures continuous and stable production.
5. 1-12 strips of PP strapping straps can be extruded at a time, depending on customer needs.
6. The winding machine can be single-station, dual-station, or automatic.
PP strapping band making machine
pp strap production line
PP packing belt making machine
pp packing belt machine
pp strap band extrusion line
Raw material:
----------- PP Polypropylene Granules
----- Accounting for over 95% of the total material, PP is the core raw material for strapping tape.
----- Features: Lightweight, wear-resistant, corrosion-resistant, high tensile strength, and low cost.
EXTRUSION PARAMETERS TABLE
| Model |
PP-2 |
PP-4 |
PP-6 |
PP-8 |
PP-10 |
PP-12 |
| Raw material |
PP polypropylene new material/recycled material |
| Number of tapes |
2 |
4 |
6 |
8 |
10 |
12 |
| Width(mm) |
5-19 |
5-19 |
5-19 |
5-19 |
5-19 |
5-19 |
| Thickness(mm) |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
| Line speed(m/min) |
≧260-300 |
| PLC control system |
PLC |
PLC |
PLC |
PLC |
PLC |
PLC |
| Screw Model |
90 |
110 |
125 |
135 |
135 |
135 |
| Reducer model |
200 |
220 |
250 |
280 |
280 |
280 |
| Winding machine |
Automatic winding machine /Semi-automatic winding machine |
| Screen Changer |
Automatic/Manua |
| Production capacity 24H |
2.5-3T |
6-7T |
8-9T |
10-11T |
12-13T |
13--14T |
DETAILS OF PP STRAPPING BAND MAKING MACHINE
Screw---------
The PP strap production machine is made of high-quality materials, including a screw made of 38CrMoALA, ensuring durability and long-lasting performance. Additionally, this machine features a video factory inspection, enabling easy and accurate quality control.
Auxiliary Feeding Section:
The PP strapping equipment is equipped with ---- 3 sets of auxiliary feeders,
Can add dyeing masterbatch------- change the color of PP strap
Can add filling masterbatch----- reduce the cost of PP strap by more than 30%
Can add defoaming agent-------- eliminate the moisture of PP raw materials
Applicable to balers:
1. Fully automatic baler
2. High-speed baler
3. Semi-automatic baler
4. Handheld electric baler
5. Manual clamp baler
FQA:
Q:What is the voltage of PP packing belt making machine ?
A:380V/50HZ, we support customization
Q:Can the PP packing belt making machine be customized according to the factory length?
A:Yes, we can customize the length according to the customer's factory size.
Q:Where is the PP packing belt making machine?
A:We are from China.
Q:Can PP packing belt making machine provide after-sales service?
A:Yes, we have professional after-sales engineers who provide 24-hour online guidance.
Q:Is the quality of PP packing belt making machine stable?
A:We have 30 years of manufacturing experience, and have their own PP packing belt making machine plant, equipment quality is stable, the process is worth choosing.
Q:Does PP packing belt making machine customization?
A:We are a manufacturing plant that can customize model size, extrusion capacity, voltage and so on according to customer requirements.
