PET plastic strap making machine 9-25mm PET strap making machine with rotary dehumidifier

PET plastic strap making machine 9-25mm PET strap making machine with rotary dehumidifier
PET plastic strap making machine 9-25mm PET strap making machine with rotary dehumidifier PET plastic strap making machine 9-25mm PET strap making machine with rotary dehumidifier PET plastic strap making machine 9-25mm PET strap making machine with rotary dehumidifier PET plastic strap making machine 9-25mm PET strap making machine with rotary dehumidifier PET plastic strap making machine 9-25mm PET strap making machine with rotary dehumidifier

Large Image :  PET plastic strap making machine 9-25mm PET strap making machine with rotary dehumidifier

Product Details:
Place of Origin: CHINA
Brand Name: JT
Certification: CE SGS
Model Number: JT-PET
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD 58000.00-129500.00
Packaging Details: plastic film
Delivery Time: 50~55 working days
Payment Terms: L/C, T/T
Supply Ability: 10-20 set/Monthly

PET plastic strap making machine 9-25mm PET strap making machine with rotary dehumidifier

Description
Raw Materials: PET Crushed Material PET Crushed Material: 9-25 Mm
Thickness: 0.3-1.2 Mm Stretching Rate: 25-30%
Control Mode: PLC Control Extension: 5 Rollers
Cooling Method: Fan Cooling Metering Pump: 100 CC

PET plastic strap making machine 9-25mm PET strap making machine with rotary dehumidifier



 Description of PET plastic strap making machine:



PET plastic strap making machine is a high-speed, intelligent, environmentally friendly plastic equipment, its advantages:



Raw materials:

PET plastic steel belt can use raw materials: 100% bottle flakes or crushed materials or thickening granular materials

1. Bottle flakes--- waste mineral water, Sprite, Coke and other bottle flakes as raw materials, after crushing, cleaning, drying materials.

2. Crushed materials---- finished PET plastic steel belt after crushing, screening, cleaning, drying raw materials;

3. Thickening granular materials----PET crushed materials after processing, cleaning, thickening granular materials



Raw materials display:

PET plastic strap making machine 9-25mm PET strap making machine with rotary dehumidifier 0



                                                      EXTRUSION PARAMETERS TABLE



Model PET-2 PET-3 PET-4 PET-6 PET-8
Raw materials 100% Bottle flakes/crushed materials
Number of tapes 2 3 4 6 8
Width (mm)   9-32
Width (mm)   0.4-1.2
Maximum line speed(m/min) ≧150 ≧150 ≧150 ≧150 ≧150
PLC control system PLC PLC PLC PLC PLC
Screw Model 90 100 125 150 180
Reducer model 200 250 280 315 350
Dryer tank 3000L 4000L 5000L 6000L 6000L
Dehumidifier 1000 1000 2000 3000 3500
Metering Pumps 100CC 100CC 100CC 100CC 100CC
Screen Changer Single cylinder
Winding machine Automatic winding/ Semi-automatic winding
Production capacity /24 H 5-6T 7-8T 10-12T 12-15T 18-20T





Features of PET plastic strap making machine:
Efficient production-----with high degree of automation and fast production speed.
High-quality products----The produced PET plastic steel belt has high strength, good toughness and strong tensile force.
Energy saving -----energy-saving design is adopted, the raw materials are mineral water bottles, which can be recycled and the manufacturing cost is low.
Easy operation----PLC automatic control, easy to operate.

PET plastic strap making machine 9-25mm PET strap making machine with rotary dehumidifier 1



PET plastic strap making machine 9-25mm PET strap making machine with rotary dehumidifier 2



Application areas

Packaging industry: used for packaging of various items, such as building materials, metals, paper products, etc.

Logistics industry: used for fixing and bundling during cargo transportation.

Other industries: such as home appliances, food, chemicals, etc.

PET plastic strap making machine 9-25mm PET strap making machine with rotary dehumidifier 3



About us:

We have nearly 30 years of production experience in the production of PP PET strapping equipment. We have our own production workshop, processing center, high-precision imported lathes, sales team, after-sales team, management team, etc.; including we currently also produce PP strapping, PET plastic steel strapping, etc., so we are very clear about the process details, the formula ratio of raw materials, and the addition ratio of various auxiliary materials;

We are the agent for the sale of various automatic strapping machines, semi-automatic strapping machines, handheld strapping machines, pneumatic strapping machines, etc., so we are clear about the requirements of different strapping machines for strapping;

We currently have 3 factories:

PP PET strapping equipment factory: 1PCS

PET plastic steel strapping factory: 1PCS

PP strapping factory: 1PCS
