9-32mm Width Plastic PET Flakes Recycling Material Strap Making Production Line With Melt Pump And Precise Die Head
Feature of PET strap making machine
1.PET strap is recognized a new environment protective strapping material to substitute for Steel Strap & PP Strap in the ruling international market.
2.They are not only the aggregation of the intensity and the tenacity of steel strap, but also overcome the disadvantage of the tradition packing material such as insufficient intensity, brittle and so on. At present, they have been applied in wood, steel, and so on.
3.Our company this line adopt the PLC control the whole line do the automatic production. It use the melting pump and pressure sensor ensure the production stable and strap quality control.
4.The raw material you can use 100% recycled PET flakes from the waste PET bottles, or virgin material or mixed with each other.
Parameter of PP PET strap making machine
| Model |
JT-PP |
JT-PET |
| Material |
PP recycled material |
PET recycled material |
| Strap Width |
5-19mm |
9-32mm |
| Thickness of strap |
0.4-1.2mm |
0.4-1.2mm |
| Production speed |
≤200-300M/min |
≤100-200M/min |
| Outlet of Die head |
1,2,4,6,8,12 straps output |
Machine parameter of PET 3 belts extrusion line
| Serial number |
Product name |
Quantity (as configuration to adjustment) |
| 1 |
Screw feeder |
3sets |
| 2 |
Horizontal mixer(2500L) |
1set |
| 3 |
Horizontal mixer(3000L) |
1set |
| 4 |
Pre-drying tower(3000L) |
1set |
| 5 |
Dehumidification and drying system |
1set |
| 6 |
Oil and dust filter |
1set |
| 7 |
Extruder part |
1 set |
| 8 |
Reducer model: 225 type |
1 set |
| 9 |
Screw: ¢ 100mm |
1 set |
| 10 |
Main engine motor |
1 set |
| 11 |
100CC Melt pump |
1set |
| 12 |
Single cylinder filter |
1 set |
| 13 |
Extrusion die head |
1 set |
| 14 |
Cooling water tank |
1 set |
| 15 |
Stretching oven |
1 set |
| 16 |
Forming oven part |
1set |
| 17 |
PLC control system |
1 set |
| 18 |
Double station winding machine |
2 sets |
PET (Polyethylene Terephthalate) strapping is a strong, durable, and recyclable plastic strapping material widely used in various industries for bundling, securing, and palletizing loads. Its high tensile strength, flexibility, and resistance to moisture and chemicals make it a popular alternative to steel and PP (polypropylene) strapping.
Application of PET strapping
1. Packaging & Logistics
Palletizing: PET strapping is commonly used to secure goods on pallets for transportation, preventing movement during transit.
Bundling: Used to bundle boxes, cartons, and other lightweight to medium-weight products.
Brick & Construction Materials: PET straps are used to bundle bricks, tiles, and other construction materials.
2. Manufacturing & Industrial Use
Paper & Printing Industry: Secures reams of paper, newspapers, and magazines.
Metal & Pipe Strapping: Used to bundle metal sheets, pipes, and rods due to its high tensile strength.
Automotive Industry: Helps bundle automotive parts and components for shipping.
3. Agriculture & Food Industry
Hay & Crop Baling: PET strapping is used to bale hay, straw, and other agricultural products.
Food Packaging: Safe for securing food products as it is non-toxic and resistant to moisture.
