Plastic Machinery Customized PP PET Automatic Wrapping Machine PP PET Strapping Wire Wrapping Machine for 120-300m/min
Product Description of Automatic strapping machine:
Product Description:
The Automatic Winding Machine is equipped with automatic paper tube change feature that allows users to change the paper tube quickly and easily. This feature saves time and effort, making the entire strapping process more efficient and productive.
One of the key features of the PET strap full-automatic winder is its use of the servo motor to lay the cable. This feature ensures that the strapping bands are evenly wound, reducing the risk of tangling and damage. The servo motor line automatic winding machine is also designed to be user-friendly, making it easy for operators to load and unload the strapping bands.
Using condition: power single-phase 220V, air pressure 4-7kgf, plug the air pipe(Φ8)in according to the marks on the equipment,connect the electronic line(2.5 m2 +).Ventilate first, then electrify(When turning off the machine in reverse order-first turn off the electricity, then turn off the air pressure).
Paper core: ø 406mm* (150MM,190MM) Spindle disc separation type (other size discs simplify the replacement possibiliy)
Line speed: 200-300 m/min
| Name |
Automatic Winding Machine |
| Tape width |
5-19mm |
| Thickness |
0.6-1.2mm |
| Control mode |
servo motor |
| Pressure |
4-7kgf |
| PLC control |
YES |
| Paper tube |
Ø200*190mm |
| Max weight |
20-350kg/roll |
| power single-phase |
220V |
| Weight |
700KG |
| Overall dimension |
(L)1400mm*(W)1200mm*(H) 1850mm |
Features of Automatic strapping machine:
- Product Name: PET Strapping Band Winding Machine
- Servo motor: YES
- Speed: 220-350m/min
- Auto wrap PE film: YES
- Adjustable tightness: YES
- Machine size: L1200*W1200*H1800mm
- Keywords: Automatic winding machine, PET strap full-automatic winder, PP strap full-automatic winder
Performance description:
A:Human-machine interface: various functions and displays in the PLC touch screen panel of the automatic winding machine (winding length, weight, start, stop, interface switching, bandwidth selection, paper core height selection, etc.)
B:The automatic winding machine replaces PP strapping tapes of different specifications and widths without replacing the transmission gears, belt grooves, etc. The back and forth axis line travel is automatically calculated by the computer, and the bandwidth spacing can be fine-tuned by the servo.
C:The automatic winding machine moves through the swing arm, and the sensor synchronously adjusts the winding speed to achieve constant tension winding.
D:Two modes of weight and meter are available, one-button control spring gas expansion disk is used, 5-19MM bandwidth arrangement is automatically calculated, and the side roller fits the guide belt to rewind, so that the finished PET belt rewinding end surface is flat, neatly arranged, uniformly spaced, and not overlapped.
Services:
After-sales service:
1. Shelf life: 12 months
2. Consumable parts: spare parts are available
3. Support 24-hour online service.
4. Free system upgrade service.
5. Remote detection service.
FAQ:
- Q1: What is the brand name of the Strapping Band Winding Machine?
- A1: The brand name of the Strapping Band Winding Machine is Automatic PP packing and winding machine.
- Q2: What is the model number of the Strapping Band Winding Machine?
- A2: The model number of the Strapping Band Winding Machine is JTPP/PET.
- Q3: What is the place of origin of the Strapping Band Winding Machine?
- A3: The place of origin of the Strapping Band Winding Machine is CHINA.
- Q4: What is the purpose of the Strapping Band Winding Machine?
- A4: The Strapping Band Winding Machine is used to automatically wind PP strapping bands.
- Q5: Does the Strapping Band Winding Machine have any special features?
- A5: Yes, the Strapping Band Winding Machine can automatically count the number of winding layers, and it is equipped with a touch screen for easy operation.
