PET belt extrusion line, PET plastic steel belt production equipment, strong tensile strength, width: 9-32mm, thickness: 0.6-1.2mm
Product Description of pet strap making machine:
1. Width---------The PET belt production line is an energy-saving and environmentally friendly plastic extruder that can produce PET belts with specifications: width: 9-32mm, thickness 0.6-1.2mm.
2. Raw materials--------The PET plastic steel belt production line can use PET bottle flakes or PET recycled materials to produce PET belts, which is an environmentally friendly manufacturing process.
3. Dehumidifier-------The dehumidification function of the PET plastic steel belt equipment is one of the important choices for this production line, and the dehumidification air volume is 1000-2000.
4. Metering pump--------The PET plastic steel belt equipment is equipped with a metering pump, 100CC-150CC, which has the advantages of uniform extrusion and consistent specifications.
5. Wrapping machine---------The PET plastic steel belt production equipment is equipped with an automatic wrapping machine or a semi-automatic wrapping machine, which can be selected.
PET strapping production line process flow:
① Loading → ② Mixing raw materials → ③ Pre-drying raw materials → ④ Vacuum dehumidification of raw materials → ⑤ Melting and metering extrusion of raw materials → ⑥ Cooling and forming of raw materials (strips) → ⑦ Oven preheating → ⑧ Primary stretching → ⑨ Secondary stretching → ⑩ Embossing → ⑪ Oven tempering and shaping → ⑫ Cooling → ⑬ Finished product winding
Technical Paramet of pet strap making machine:
| Name |
PET Strap Extrusion Line |
| Paper core specification |
￠ 406*150mm |
| Automation |
PLC Computer Touch Screen |
| Strap Width |
9-32mm |
| Strap Tension |
>10000kg |
| Reducer specification |
280# |
| Winder |
Manual/automatic |
| Metering pump |
100CC |
| PLC computer touch screen |
1set |
Applications of pet strap making machine:
Dehumidifier:
The dehumidifier of the PET strapping production line adopts a honeycomb rotor, which mainly removes the internal moisture of the raw materials. The minimum air volume can reach more than 1000. The temperature is about 200 degrees.
PET plastic steel belt equipment dust filter purpose: mainly to filter and clean the dust of the raw materials, clean the filter element about once a day, and the oil removal part is cleaned about once every 3-6 months
Support and Services:
The PET Strap Extrusion Line is a state-of-the-art product that requires expert technical support and services to ensure optimal performance and longevity. Our team of experienced technicians is available to provide assistance with installation, maintenance, and troubleshooting. We also offer training programs to ensure that operators are equipped with the knowledge and skills necessary to operate the machine safely and efficiently. Our services include:
- Installation and commissioning
- Preventive maintenance
- Emergency repairs
- Remote technical support
- On-site technical support
- Training programs for operators and maintenance personnel
- Upgrades and retrofits
FAQ:
Q: What is the brand name of this PET Strap Extrusion Line?-------JIATUO CHINA.
Q: What is the model number of this PET Strap Extrusion Line?-----JTPET-100
Q: Does this PET Strap Extrusion Line have any certifications?------CE, SGS, and ISO.
Q: What is the minimum order quantity for this PET Strap Extrusion Line?------1 set.
Q: What is the packaging and extrusion capacity of this PET tape extrusion line?-----200-600KG/H
Q:What is the delivery time for this PET tape extrusion line? --------50-60 Day
