Automatic binding tape winding machine, PET plastic steel tape winding machine, automatic winding machine, 80kg/ coil
Product Description of PET plastic steel tape winding machine:
1.Using condition: power single-phase 220V, air pressure 4-7kgf, plug the air pipe(Φ8)in according to the marks on the equipment,connect the electronic line(2.5 m2 +).Ventilate first, then electrify(When turning off the machine in reverse order-first turn off the electricity, then turn off the air pressure).
2.Paper core: ø 406mm* (150MM,190MM) Spindle disc separation type (other size discs simplify the replacement possibiliy).
3.Dimensions :(about) length 1200MM* width 1200MM* height 1850MM.
4.The weight can reach 80KG/ roll.
Features of PET plastic steel tape winding machine:
- Product Name: PET Strapping Band Winding Machine
- Strap Width:9-32mm
- Thickness:0.6-1.2mm
- Size: Customized
- Machine size: L1200*W1200*H1800mm
- Application: Packaging Industry
- Features:
- PET automatic winder
- PET strap full-automatic winder
- PP STRAP WINDER DUAL-SERVO MOTOR
Technical Parameters of PET plastic steel tape winding machine:
| Product Name: |
Strapping Band Winding Machine |
| Paper tube: |
¢406mm * 150mm |
| No manual volume change is required: |
YES |
| Automatic paper tube change: |
YES |
| Tension Range: |
80-500kg |
| Use servo motor to lay the cable: |
YES |
| Automatic winding: |
YES |
| Power Consumption: |
1.8KW |
| Automatic stop: |
YES |
| Warranty: |
12 Months |
Applications of PET plastic steel tape winding machine:
1..Man-machine interface: operation and display of various functions in the touch screen panel (winding length, weight, start, stop, interface switching, bandwidth selection, paper core height selection, etc.)
2,.Strap band width replacement no need gears change, back and forth line travel automatically calculated, bandwidth spacing can be fine-tuned by servo.
3,.Constant tension winding is realized by synchronizing the winding speed with the displacement sensor of the swing arm.
4.Metering mode selection in weight and meter 2, the use of one-button spring air tension plate, 9 - 32mm bandwidth arrangement automatic calculation, side roller fitting type belt winding, winding end face smooth, even spacing.
Customization:
Brand Name: Automatic PP/ PET packing and winding machine
Model Number: JTPP/PET
Place of Origin: CHINA
30 years old brand: YES
Product Name: Strapping Band Winding Machine
Touch screen control: YES
PLC, touch screen: Xinjie
Name: Automatic Winding Machine
Our customization services include:
- Servo motor line automatic winding machine
- PP STRAP WINDER DUAL-SERVO MOTOR
- Automatic winding machine
Support and Services:
- Regular maintenance and servicing
- Repairs and replacement of parts
- Training for operators and maintenance personnel
- Customization options to meet your specific needs
Packing and Shipping:
Product Packaging:
- 1 Strapping Band Winding Machine
- User manual
- Power cord
