This is a PP strapping tape automatic winding machine/servo winding machine, PP packing tape automatic winding machine, width: 5-19mm, line neatly, automatic adjustment, no need to manually change the paper core.
1) Use the servo motor to lay the cable, wrap the strap with a width of 5-19 mm, and select the corresponding bandwidth through the touch screen for winding. There is no need to manually replace the transmission gear.
2) After the winding is completed, the machine will stop automatically, replace the paper tube, cut off the packing belt and clip the packing head to fix the packing head, and the winding operation will be carried out automatically, and the whole process will be completed automatically.
3) The winding shaft uses the torque mode of the servo motor, and the torque during winding can be set through the touch screen, so that the packaging belts with different weights or widths can be rolled with appropriate torque, and the bending deformation of the packaging belt after winding can be minimized.
4) The exiting packing belt after winding is automatically moved to the storage belt conveyor, where about 3 rolls of packing belt can be placed, or the conveyor belt can be lengthened according to customer requirements.
Paper tube: 203mm * 165~195mm paper tube, with a thickness of 5MM, which is not available for recycling worn paper tubes.
Features of PP packing tape automatic winding machine:
- Product Name: PP/PET Strapping Band Winding Machine
- Automatic winding machine: YES
- PET automatic winder: YES
- No manual volume change is required: YES
- Machine size: L1200*W1200*H1800mm
- Tension Range: 80-500kg
- Servo motor: YES
Technical Parameters of PP packing tape automatic winding machine:
| Name |
PP/PET Strapping Band Winding Machine |
| Automatic stop |
YES |
| Automatic rewinding |
YES |
| Product Name |
Strapping Band Winding Machine |
| Automatic winding |
YES |
| No manual volume change is required |
YES |
| Machine size |
L1200*W1200*H1800mm |
| Touch screen control |
YES |
| Servo motor |
YES |
| Tension Range |
80-500kg |
| Output description |
Servo winding machine, Automatically stop the winder |
Applications of PP packing tape automatic winding machine:
The machine is designed to wind PP straps, and it has a paper tube of ¢406mm * 150mm. It is equipped with a dual-servo motor that ensures that the winding process is smooth and efficient. The servo motor line automatic winding machine is easy to operate, and it comes with a PLC computer touch screen that makes it easy to control the machine's functions.
The Automatic PP/ PET packing and winding machine is ideal for use in various industries. The machine is suitable for use in packing and logistics companies, manufacturing plants, and warehouses. It is perfect for winding packing tapes, and it guarantees the safety of your goods during transportation.
The strapping band winding machine is also perfect for use in industries that require the winding of large volumes of packing tapes. The machine's dual-servo motor ensures that the winding process is fast and efficient, and it saves time and manpower.
The machine's design is compact and takes up minimal space, making it ideal for use in small and medium-sized companies. The product name, Strapping Band Winding Machine, is descriptive of its primary function, which is to wind strapping bands. The machine is easy to install, and it comes with a warranty of 12 months.
Customization of PP packing tape automatic winding machine:
Product Attributes:
- Brand Name: Automatic PP/ PET packing and winding machine
- Model Number: JTPP/PET
- Place of Origin: CHINA
- Use the servo motor to lay the cable: YES
- Touch screen control: YES
- Application: Packaging Industry
- Name: Automatic Winding Machine
- Machine size: L1200*W1200*H1800mm
Support and Services of PP packing tape automatic winding machine:
The Strapping Band Winding Machine is a robust and reliable piece of equipment that requires minimal technical support and services. However, in the unlikely event of any issues, our team of experienced technicians is available to provide prompt and efficient assistance. Our technical support and services include:
- Remote troubleshooting and diagnosis
- On-site repair and maintenance
- Replacement of faulty parts
- Training and guidance on proper usage and maintenance
We also offer customized service packages to suit your specific needs and requirements. Contact us for more information.
FAQ:
Q: What is the brand name of this strapping band winding machine?
A: The brand name of this machine is Automatic PP/ PET packing and winding machine.
Q: What is the model number of this machine?
A: The model number of this machine is JTPP/PET.
Q: Where is this machine manufactured?
A: This machine is manufactured in China.
Q: What type of packing material can this machine handle?
A: This machine can handle both PP (polypropylene) and PET (polyethylene terephthalate) strapping bands.
Q: Is this machine suitable for heavy-duty usage?
A: Yes, this machine is designed to handle heavy-duty usage and can wind large quantities of strapping bands efficiently.
