Automatic Winding PP Polypropylene Extrusion Equipment 220V/380V/440V

Automatic winding PP polypropylene extrusion equipment 220V/380V/440V

Product Description of PP packing tape automatic winding machine:

►Strapping Band Winding Machine is an advanced PET automatic winder which is specially designed for the packing industry. It is equipped with PLC and a touch screen from Xinjie to make the operation more convenient. This machine is designed for winding paper tubes with a size of ¢203mm * 165~195mm, and can be used to wind the straps with a thickness of 0.4-1.2mm. In addition, it is equipped with servo motor wiring to make the winding process more efficient. This Strapping Band Winding Machine is perfect for those who need a reliable and efficient winder for their packing tape winding, and it is ideal for the packing industry.
►Using condition: power single-phase 220V, air pressure 4-7kgf, plug the air pipe(Φ8)in according to the marks on the equipment,connect the electronic line(2.5 m2 +).Ventilate first, then electrify(When turning off the machine in reverse order-first turn off the electricity, then turn off the air pressure).
►use the servo motor to lay the cable, and wind up the PP STRAP with the width of 7-19mm. Select the corresponding bandwidth through the touch screen to wind up, and there is no need to manually replace the transmission gear.
►After the winding is completed, the machine will stop automatically, replace the paper tube, cut off the PP STRAP and clamp the pieces to fix the STRAP head, and the winding operation will be carried out automatically, and the whole process will be completed automatically.
►The winding shaft uses the torque mode of servo motor, and the torque during winding can be set through the touch screen, so that the PP STRAP with different gram weight or width can be wound with appropriate torque, so be best to minimize the bending deformation of the PP STRAP after winding.
►After the winding is completed, the exiting packing belt will automatically move to the storage belt conveyor. About 3 rolls can be placed on the conveyor, and it can also be lengthened according to the needs of customers.
►Paper tube: 203mm * 165~195mm paper tube, 10mm thick, recycling old paper tube is not available.



Features of PP packing tape automatic winding machine:

• Product Name: Strapping Band Winding Machine
• No need to change gears: YES
• Feature: Full-automatic Winder
• PLC, touch screen: Xinjie
• No manual volume change is required: YES
• Name: Automatic Winding Machine
• Keywords: Automatic winder, Packing tape winder, Servo motor line automatic winding machine

Technical Parameters of PP packing tape automatic winding machine:

Applications of PP packing tape automatic winding machine:

The Automatic PP packing and winding machine is an ideal choice for businesses looking for an efficient and reliable solution for their strapping and winding needs. This model, the JTPP/PET, is manufactured in China and features a servo motor wiring system. It also has a servo motor that can be used to lay the cable, eliminating the need for manual volume changes. This machine is capable of handling straps up to 5-19mm wide, and it weighs a mere 650kg. With its efficient design and superior performance, this machine is the perfect choice for businesses looking for an automated strapping and winding solution.

Customization:of PP packing tape automatic winding mach

Brand Name: Automatic PP packing and winding machine
Model Number: JTPP/PET
Place of Origin: CHINA
Air pressure: 4-7kgf
Size: Customized
PLC, touch screen: Xinjie
Servo motor wiring: YES
Machine size: L1900*W1850*H1800mm
Our Strapping Band Winding Machine is a PP strap full-automatic winder, specially designed with PP STRAP WINDER DUAL-SERVO MOTOR. It can make sure a stable and reliable working performance. This Automatic winding machine is also equipped with the touch screen and PLC from Xinjie, making sure easy operation and accurate winding. The size of this machine can be customized according to your specific needs.

Support and Services of PP packing tape automatic winding machine:

We provide a comprehensive technical support and service for Strapping Band Winding Machine. Our team of experienced technicians are available to offer assistance with installation, maintenance, repairs, and troubleshooting.

Our technicians are available to install your Strapping Band Winding Machine. We will ensure that the equipment is configured correctly and is operational. We can also provide advice and guidance on best practices for safe and efficient use.

We can provide regular maintenance for your Strapping Band Winding Machine to ensure it is in good working order. This includes checking for potential problems, cleaning, and replacing worn parts.

If your Strapping Band Winding Machine malfunctions, our technicians can diagnose and repair the problem. We can also provide advice on preventive measures to minimize the risk of future breakdowns.

We can help you identify and resolve any issues you may have with your Strapping Band Winding Machine. Our technicians are available to provide guidance and assistance.

Packing and Shipping of PP packing tape automatic winding machine:

Packaging and Shipping for Strapping Band Winding Machine:
The Strapping Band Winding Machine is packaged in a robust cardboard box, and it is shipped by air to the customer's destination. The box is sealed with a plastic band to ensure safety during transportation. The package also includes a user manual and an instruction booklet, so that customers can easily install and use the product.
