Polypropylene PP Strap Band Extrusion Line Recycled Pellets Material

Polypropylene PP Strap Band Extrusion Line Recycled Pellets Material
Polypropylene PP Strap Band Extrusion Line Recycled Pellets Material
Polypropylene PP Strap Band Extrusion Line Recycled Pellets Material Polypropylene PP Strap Band Extrusion Line Recycled Pellets Material Polypropylene PP Strap Band Extrusion Line Recycled Pellets Material Polypropylene PP Strap Band Extrusion Line Recycled Pellets Material Polypropylene PP Strap Band Extrusion Line Recycled Pellets Material

Large Image :  Polypropylene PP Strap Band Extrusion Line Recycled Pellets Material

Product Details:
Place of Origin: Shenzhen, China
Brand Name: JIATUO
Certification: CE, ISO
Model Number: JTPP-90
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plastic film or other standard package for sea shipping
Delivery Time: 30-35 working days
Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability: 50set/month

Polypropylene PP Strap Band Extrusion Line Recycled Pellets Material

Description
Product Type: Plastic Pp Strapping Band Production Line/PP Strap Extrusion Machine/PP Packing Making Machine Raw Material: Polypropylene PP Raw Material Pellets, Recycled Pellets
Screw Design: Optional Twin Screw Type: Co-rotating Parallel Twin-screw
Driven Type: Electric Processing Type: Extruding Machine
Automation: Automatic Application: Packaging Strap
Highlight:

Polypropylene PP Strap Band Extrusion Line

,

1.2mm PP Strap Band Extrusion Line

,

200kg PP Packing Strap Making Machine





Description of  PP Strapping Production Line:

Name: PP 1 to 4 strapping production line

Model number: JTPP-110

Applicable raw materials: New PP particles, PP recycled materials, PP crushed materials

Number of screws: 1 Screw

Number of extruded belts: 4

Width range: 5-19mm

Thickness range: 0.4-1.2mm

Production capacity: 200kg/h

Installation size: L38*W2.0*H4.0(m)

Polypropylene PP Strap Band Extrusion Line Recycled Pellets Material 0


Configuration Of PP Strapping Production Line

NO. Name QTY
1 Color Mixer 1 set
2 Vacuum feeder or screw loader feeder
(100% raw material use vacuum feeder machine;recycled material use screw loader feeder machine) customer choose one of it.
1 set
3 Hopper dryer 1 set
4 SJ single screw extruder 1 set
5 High speed Screen exchanger device 1 set
6 Molud 1 set
7 Water cooling tank 1 set
8 The first traction machine- 5 rollers 1 set
9 The first Stretch forming oven 1 set
10 The Second traction machine- 5 rollers 1 set
11 The second Stretch forming oven 1 set
12 The Third traction machine- 3 rollers 1 set
13 Embossing machine 1 set
14 The Winder machine 1 set



Polypropylene PP Strap Band Extrusion Line Recycled Pellets Material 1

Features Of PP Strap Extrusion Line



Solemnly declare: This machine has been improved by our company and has core technology. It is inconvenient to upload detailed pictures and videos. Please forgive us. Welcome to visit and inspect.The machine shall prevail in kind.



PP PET packing belt production line features:
PP Plastic packing belt making machine PET strap tape extruding machine
1. Production of raw materials can be used to produce packaging belts with recycled materials or mixed new materials. It is also possible to add calcium carbonate according to customer conditions to reduce production costs, increase product profit, and market competitiveness.
2. The output is high, and the finished line speed can reach 260m/min.
3. The appearance of the whole machine has been optimized, beautiful and high-grade, durable and durable.
4. High-precision die parts make the product forming quality stable, width and thickness fluctuations are far less than the
national standard; unique network changing device greatly reduces the network changing time.
5. High-precision high-quality screw, using well-known brand, unique parameter design, with the advantages of large extrusion,good plasticization, high hardness and high wear resistance.
6. Configure special hardened gear reducer, high speed wear and long service life.





Polypropylene PP Strap Band Extrusion Line Recycled Pellets Material 2
About after-sales service:

1. We provide PP packing tape production formula.

2. We provide technical guidance for PP packing tape.

3. We provide cost analysis of PP packaging tape.

4. We provide market project analysis of PP packaging tape.

5. We provide PP packing tape raw material manufacturers.

6. We provide installation guidance for PP packaging and tape production equipment.

7. We provide PP packaging belt production equipment waterway, circuit, line drawings.

8. We provide lifelong maintenance service for PP packing belt production line.
