Automatic Screen Changer PP Strap Making Machine 4 Extrusion Line 240kgs/H

Large Image : Automatic Screen Changer PP Strap Making Machine 4 Extrusion Line 240kgs/H

Product Details:

Place of Origin:	CHINA
Brand Name:	JIATUO CHINA
Certification:	ISO/ CE
Model Number:	JTPP-110

Payment & Shipping Terms:

Minimum Order Quantity:	1 SET
Price:	Negotiable
Packaging Details:	Plastic film
Delivery Time:	50-60DAYS To be negotiated
Payment Terms:	L/C, T/T

Contact Now

Automatic Screen Changer PP Strap Making Machine 4 Extrusion Line 240kgs/H

Description

Plastic Processed:	PP	Screw Diameter (mm):	110mm
Production Capacity:	240-280kgs/H	Warranty:	1 Years
Number Of Extruded Strap:	4	Application Scope:	Some Light Cargoes (>240kgs)
Screen Changer:	Automatic/handle	Thickness Range:	0.4-1.2mm
Width Range:	5-19mm	Applicable Raw Materials:	100% Recycled Material
Melting Point:	260 Temperature	Keywords:	Strap Making Machine
Key Selling Points:	High Productivity	Automatic Grade:	Fully Automatic/ Semi Automatic
Motor Power:	Siemens	Color:	Customizable
Highlight:	1.2mm PP Strap Making Machine , 240kg PP Strap Making Machine , 240kg pp strap making machine

Automatic Screen Changer PP Strap Extrusion 4 Line Machine 240kgs/H

Description of PP strap band production machine:

PP strap production line is used to produce mechanical or manual bands with 100% PP recycled granules as materials, if using raw materials, it will be better and will be more shiny. This kind of band is widely used in the packing of kinds of fields such as mines, general merchandise, weaving, electrical equipment, apparatus, architecture, medicine, etc. more industry will use the PP strap to packing the cargoes, it can bear more weight than any other general packing material, like tape, rope etc.

Automatic Screen Changer PP Strap Making Machine 4 Extrusion Line 240kgs/H 0

System Configuration of the PP Production Line:

Screw Feeder 1 set
Hopper dryer 1 set
Feeding machine 2 set
¢110 Extruding Machine 1 set
Automatic Screen filter changer 1 set
Mould(1 mould for 4 output) 1 set
Water cooling tank system 1 set
The first haul-off device 1 set
Stretching oven 1 set
The second haul-off device 1 set
PLC electrical control system 1 set
Embossing machine 1 set
Forming oven 1 set
Cooling system 1 set
The third haul-off device 1 set
Double disk winder 4 set

Parameters of PP Belt Strapping Band Production Line:

1	Materials	Polypropylene PP raw material pellets, recycled pellets.
2	Product	PP strap (1 mould for 4 straps)
3	Capacity	200-230kg/h
4	Total install power	100kw, (actual power consumption is 50-60%)
5	Strap width	5mm-19 mm
6	Thickness	0.4 mm-1.2 mm
7	Manpower	2person/shift
8	Workshop required	L (36m) ×W (2m) ×H (4m)
9	Cooling water	≤20℃,≥0.3Mpa, 5-8Ton/hr
10	Compressed air	0.5-0.8Mpa
11	Power source	380V, 50Hz, 3Phase (according to customer requirement)
12	Electric components	Schneider
13	Inverter	INVT
14	Switches	Fotek
15	Motor power	Siemens
16	Machine frame	1001002.5 mm(GB quadrate pipe)

Automatic Screen Changer PP Strap Making Machine 4 Extrusion Line 240kgs/H 1

Advantages for PP Making Machine:

This line is specially designed for the production of PP Straps. It can produce 4 PP Straps at the same time that saves energy by 20%-30%
Both the Shaping Water Tank and Calibrating Tank are made of stainless steel that the tanks are long-lived
PLC Controller by touching keys with English and Chinese languages, which is safe and easy to operate that keeps good status of all part and ensures the stable performance of whole line and continuous production of PP Straps.
PP raw materials do not need to separate the dry and water treatment . There are automatic circulation on preheating and

drying that save a large number of equipment investment and reduce the production cost by 30%

Automatic Screen Changer PP Strap Making Machine 4 Extrusion Line 240kgs/H 2
