9 - 32mm PET Strap Making Machine With Non Stop Auotomatic Filter

9 - 32mm PET Strap Making Machine With Non Stop Auotomatic Filter
9 - 32mm PET Strap Making Machine With Non Stop Auotomatic Filter 9 - 32mm PET Strap Making Machine With Non Stop Auotomatic Filter 9 - 32mm PET Strap Making Machine With Non Stop Auotomatic Filter

Large Image :  9 - 32mm PET Strap Making Machine With Non Stop Auotomatic Filter

Product Details:
Place of Origin: Shenzhen, China
Brand Name: JIATUO
Certification: CE, ISO
Model Number: JTPET-100
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plastic film or other standard package for sea shipping
Delivery Time: 50~55 working days
Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability: 50 set/month

9 - 32mm PET Strap Making Machine With Non Stop Auotomatic Filter

Description
Product Type: PET Strap Making Machine Raw Material: PET Flakes Or 100% Recycled Material
PET Strap Width: 9-32mm Capacity: 200kg/h
PET Thickness Range: 0.6-12mm Driven Type: Electric
Voltage: According To Customer's Factory Product Color: Green/Pink/yellow/black
Motor: Siemens After-sales Service Provided: Video Technical Support, Online Support
Application: Packaged Material Warranty: 1 Year
Highlight:

32mm PET Strap Making Machine

,

Auotomatic Filter PET Strap Making Machine

,

Siemens Motor pet strap manufacturing machine

PET Strap Making Machine PET Package Band With Non-Stop Auotomatic Filter


PRODUCT DESCRIPTION

PET strap production line Function and Advantage:

High tensile strength, limited elongation, good impact resistance, economic, convenient operation and safety. It is an ideal substitution of traditional steel strap.
Packing for paper, wood, cotton, fiber, metal, aluminum-plastic profile products and various pallets.



Features pet strap production line:
1, Special twin screw extrusion technology and single screw extrusion technology, can be choose as per customer needs

2, Process 100% recycled PET bottle flakes( After Grace-M PET washing and recycling line)

3, Even plasticization and stable extrusion with PC automatic control for the full line

4, As per different requirements, changing A coating materials for make strap have better and special function. Foe example, the strap for packing cotton, can be from enhancing the breaking strength and joint strength when welding strap

5, Melt filter with two pistons with air venting design and backflusing

6, Number of strap: 1, 2, 4, 6



PET Strap Production Line Machine List

NO. Item Specification
1 Power According to customer's factory voltage
2 Material PET raw material or 100% PET bottle flakes recycled
3 Capacity

PETJT90:200kg/h

PETJT100:250kg/h

PETJT125:350kg/h

4 Product size

Width:9-32mm

Thickness:0.6-12mm

6 Mid-height of extruder 7000mm
7 Installation power

PETJT90:200KW

PETJT100:250KW

PETJT125:300KW

8 Humidity <85%
9 Temperature 0-40 degree
10 Cooling tower capacity 30T/H or 50T/H
11 Installation Dimensions

PETJT90:45*2.0*7.0M

PETJT100:45*2.0*7.0M

PETJT125:60*3.0*8.0M

12 Product color Green/Black/Pink/Yellow
13 Factory dimension

35m*(3~6)m*(4~6)m

45m*(3~6)m*(4~6)m

If your factory not big enough,please contact with us,our engineer can according to your size to design

9 - 32mm PET Strap Making Machine With Non Stop Auotomatic Filter 0
Advantages of PET strap

1. Using the recycling bottle slices as raw materials by making them melt directly,
which reduces the course of raw material-making


2. With the multi-purpose machine, it can produce PET straps in different specifications
directly and doesn't need to change the mould head


3. The products has the same transparency as made from new polyester slices, but
the tensile strength and shock resistance are stronger


4. Low energy consumption, high production capability


5. Easy to operate, saves manpower

9 - 32mm PET Strap Making Machine With Non Stop Auotomatic Filter 1

Features of PET packing strap production line:

  • 1. Better tensile strength: the PET strap production line has the tensile strength of the steel belt, and the ductility is good, and the anti-impact performance is better. It is not easy to break, and it can ensure the safety of product transportation.

  • 2. Strong temperature resistance: the experiment proved that the melting point of PET packing belt at about 260 ℃, can be used under the environment of 120 ℃ for a long time not to distort,it has a good stability.

  • 3. Good economic benefit: the density of PET packaging belt is 1.30 ~ 1.38 g/cm3, which is only 1/6 of the steel belt density (7.8 g/cm3), which is equivalent to the length of the 6-ton steel belt, and the price of the same unit length is relatively low.

  • 4. Environmentally friendly: the steel belt will rust due to exposure to the air, and the rust is highly permeable to the packaging. PET packing tape is beautiful and not rusted, but avoid unnecessary worry. It can also be recycled.

  • 5. Small extension: Although PET strap is one kind of plastics, its extension of change is very small, its elongation is only 1/ 6 of polypropylene, it can maintain tension force, after the packing make the expansion no longer change.

  • 6. Good flexibility and safe operation: the PET packing strip has no sharp edge with steel belt, it will not scratch the package, and it will not hurt the hand. You don’t need a special tool when you cut it, even if it’s tight, it doesn’t hurt when you cut it.

  • 7.High quality packaging ideal products: PET packaging with all kinds of bright colors, shiny, high quality, the most ideal packaging products of high-end packaging

9 - 32mm PET Strap Making Machine With Non Stop Auotomatic Filter 2
