200kg/H Plastic PET Strap Making Machine GUGAO Motor Electric Driven
PRODUCT DESCRIPTION OF PET STRAPPING
PET strap is an alternative to steel strapping, polypropylene strapping material such as new environmentally friendly packaging materials, mainly used for all kinds of Strapping, such as pallets, cartons, boxes, plastic boxes and other types of bundled packaging. It also can be used for direct binding, for example: cotton, steel, timber and other packaging.
Now it widely used in cotton, steel, paper, chemical fiber, electronics, food, timber, building materials, packaging and other industries area.
Specification of PET Strap Production Line Machine
| 1 |
Materials |
PET crushed material/ bottle flakes material /virgin material |
| 2 |
Product |
PET strap (1 mould for 2straps) |
| 3 |
Capacity |
200-225kg/H |
| 4 |
Total install power |
100kw, (actual power consumption is 40-50%) |
| 5 |
Strap width |
9mm-32 mm |
| 6 |
Thickness |
0.4 mm-1.2 mm |
| 7 |
Manpower |
2person/shift |
| 8 |
Workshop required |
L (50m) ×W (4m) ×H (8m) |
| 9 |
Power source |
380V, 50Hz, 3Phase (according to customer requirement) |
| 10 |
Electric components |
Schneider |
| 11 |
Inverter |
INVT |
| 12 |
Switches |
Fotek |
| 13 |
Motor power |
GUGAO |
DETAILS ABOUT PET STRAP MAKING MACHINE
1.Production Process of PET Machinery
Material→ Dehumidifying and Crystallizing → Extruding → Mold → Cooling → Haul-off →Oven Heating →Pre-heating → Drawing and Stretching →Drawing and Stretching → Embossing →Hot Forming → Drawing → Winding
2. winder machine choose
- semi-automatic winding machine
- fully-automatic winding machine
Features of PET packing strap production line
1) PP PET raw materials do not need to separate the dry and water treatment . There are automatic circulation on preheating and drying that save a large number of equipment investment and reduce the production cost by 30%;
2) Utilizing the retrieving bottle slice as raw materials that reducing the cost to a great extent;
3) With the multi-purpose machine, produce the PP PET straps in different specifications directly and dont need to change the mould head;
4) Comparing with new polyester slice, the transparency of products is just the same, but the tensile strength and shock resistance are up to the international grade;
5) Low Energy consumption, but high production capability;
6)Easy to operate, save the manpower and two persons for one production line on average.
FAQ
Q: Are you the manufacturer?
A: Yes, we are the manufacturer of PP and PET strap making machine for nearly 30years experience. And also we have our own PP PET strapping factory.
Q:What is the voltage of PET strap making equipment?
A:380V/50HZ, we support customization
Q:Can the PET strapping production equipment be customized according to the factory length?
A:Yes, we can customize the length according to the customer's factory size.
Q:Where is the PET strapping equipment produced?
A:We are from China.
