Single Cylinder Filter PET Packaging Belt Production Line With No-Stop Changer

Large Image : Single Cylinder Filter PET Packaging Belt Production Line With No-Stop Changer

Product Details:

Place of Origin:	CHINA
Brand Name:	JIATUO CHINA
Certification:	CE SGS ISO
Model Number:	JTPET-90

Payment & Shipping Terms:

Minimum Order Quantity:	1 SET
Price:	Negotiable
Packaging Details:	plastic film
Delivery Time:	30-40 Days
Payment Terms:	L/C, T/T
Supply Ability:	10000sets

Contact Now

Single Cylinder Filter PET Packaging Belt Production Line With No-Stop Changer

Description

Product Name:	PET Strap Extrusion Line	Material:	PET Bottle Flakes Material/PET Recycle Material
Power Supply:	380V/50Hz/220V/60HZ Three-phase	Automation:	PLC Computer Touch Screen
Oil Removal And Dust Removal Filter:	1set	Main Motor:	37KW(Siemens)
Neat Winding:	YES	Pre Drying Tower:	5000L
Production Capacity:	220-250kg/H
Highlight:	PET Packaging Belt Production Line , Single Cylinder Filter PET Strap Extruder , No-Stop Changer PET Strap Extruder

Single Cylinder Filter PET Packaging Belt Production Line With No-Stop Changer

Technical parameters of PET belt 2output production line

Screw model	90 (Single screw or double screw)
Number of strap	2 straps
Width	9-32mm
Thickness	0.4-1.2mm
Screen changer	Automatic/Manual
Control system	PLC control(Chinese and English)
Production capacity	220-250kg/H
Reducer Brand	GUOMAO
Motor Brand	Siemens
Pull of finial product	150kg-900kg
Line speed	More than 160m/min
Material	PET crushed material/bottle flake material

PET packaging belt production line process

Material→mixing material→pre-drying material →dehumidification and drying material→Melting material and extrusion→material embryo expression(with embryo) cooling molding→pre-heating oven→firstly streching→secondary stretching→embossing→setting oven to shaping→cooling→Final product winder

Description of PET belt making machine

Packing belts are very common in life. It is needed to complete the packaging and fixing of goods. So its usage rate is very high.
PET packaging belt production line, including, drying, extrusion, traction, stretching, fixing, winding, and other parts.
It is characterized by fast speed, large production capacity and high safety.

Single Cylinder Filter PET Packaging Belt Production Line With No-Stop Changer 1
