PP Belt Semi Automatic Bale Speed 2.5 Seconds/Strip Carton Box Strapping Machine

Large Image : PP Belt Semi Automatic Bale Speed 2.5 Seconds/Strip Carton Box Strapping Machine

Product Details:

Place of Origin:	CHINA
Brand Name:	JIATUO CHINA
Certification:	ISO CE
Model Number:	JT-313D

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	RMB: 3500-3800/1set
Packaging Details:	wooden case
Delivery Time:	7-15days

Contact Now

PP Belt Semi Automatic Bale Speed 2.5 Seconds/Strip Carton Box Strapping Machine

Description

Product Name:	Semi-Automatic Box Strapping Machine	Material:	Metal
Packaging Material:	Packaging Material	Automatic Grade:	Semi-automatic
Package Weight:	80Kg	Power:	0.75KW
Size:	Customized	Speed:	20-30m/min
Strap Thickness:	0.4-1.2mm	Strap Width:	6-15mm
Tension:	15-45Kg	Voltage:	110/220V/380/440 .1HP
Warranty:	1 Year	Driven Type:	Electric
Machinery Test Report:	Provided

PP Belt Semi Automatic Bale Speed 2.5 Seconds/Strip Carton Box Strapping Machine

PRODUCT DESCRIPTION ABOUT PACKING MACHINE
1. Suitable for packing tape width: 6-15mm (adjustable)
2. Bale speed: 2.5 seconds/strip
3. Power supply voltage: 110/220V.1PH
4. Binding force: 15-45KGs
5. Machine size: (L) 902* (W) 575* (H) 780
6. Machine plate color: can be customized according to customer requirements, OEM

7.Strip Carton Box Strapping Machine

Cycle Time	2.5 sec./strap
Tension Range	15~45kgs
Strap Width	9,12,13.5,15.5mm adjustable
Sealing Method	Heating element
Reel Inside Diameter	200,230,280mm specified
Reel Inside Diameter	200,230,280mm specified
Power Supply	100/110/220/230/240V 50/60HZ, 1PH
Table Height	780mm
Power Consumption	0.4kw
Machine Dimension	(L x W x H mm)L902 x W575 x H780
Machine Weight	90ks
Color Machine	red yello blue gray gray customizable

PP Belt Semi Automatic Bale Speed 2.5 Seconds/Strip Carton Box Strapping Machine 1

Feature description of packer:
1. Collapsible desktop design, easy maintenance.
2. Strong structure and beautiful shape
More than 50 years production experience of baling machine, stable quality.
4 motor automatic power outage, equipment power saving, durable.
5. Fast heating design, heating fast, and safe.
6. Equipped with auxiliary tape feeding and cutting switch, the length of the tape feeding can be adjusted, easy to use.
7. Equipped with wearing parts randomly

PP Belt Semi Automatic Bale Speed 2.5 Seconds/Strip Carton Box Strapping Machine 3

How to use semi-automatic strapping machine:

1. Power switch: Turn ON to start the machine, and OFF to stop the machine.
2. Power indicator light (POWER): Turn on the power switch, the light is on.
3. Length adjustment for strap feeding (TIMER): Every one scale is about 500mm.For any adjustment that is required turn it in the clockwise direction. The length of the strap will then become longer.
4. Strap tension button (TENSION): Choose the tension degree of a strap according to the size of the package.
5. Manual feeding/Reset button (FEED/HOME): Press the FEED button to help feed the straps. The longer you press, the longer the strap will be. 6. If the machine is not at the home position, press the HOME button so that the machine will return to its home position.
7. Cooling time adjustment (COOL TIME): Depending on the strap and the different tensile strength, adjust the cooling time, for better adhesion effects.
8. Safety door switch: If the top cover is opened, the machine will stop running automatically. (Please turn off the main power switch before opening top cover.

PP Belt Semi Automatic Bale Speed 2.5 Seconds/Strip Carton Box Strapping Machine 4
